Stick system curtain wall EFP 50 TSV

insulated glass panelaluminum and glasshigh-resistance

CURTAIN WALL system enables the construction of attractive 2 sided structural glazed curtain walling, with the benefits of slim vertical (TSH) sightlines or if desired vertical design features by using different cover caps. This thermally insulated system consist of many standard profiles and many custom made profiles are available up on request. Specification summary: EFP 50 TSV is a pressure equalised, mullion drained, thermally broken curtain wall system which consists of 50 mm wide mullions and transoms. The external horizontal sightline (Joint seal) is 20mm. The joint seal is made out of extruded EPDM or Silicone profiles, compatible with most silicone sealants, optional this joint can also be made out of silicone sealant. Various cover caps are available for this system.The smallest sight line can be achieved using a 50mm wide cap. Cover caps have a typical edge radius of 1.5mm, edge radii for even distribution of the powder coating layer.
