Installation
Wire suspension. The wire pendant can be secured directly to the body or via a bracket. Wire lock mounted in the luminaire body. Continuous coupler available as an accessory.
Connection
The luminaire is fitted with a 2.4 m mains cable 3x1 mm² and an earthed plug. The mains cable enters on the same side as the pull-cord, if fitted. Luminaires with cat no -436 and -368 are delivered with a 2.4 m mains cable 5x0.75 mm² excl plug.
Design
Sheet steel luminaire body in white (RAL 9016) or alu-grey (RAL 9006) structured enamelled finish. The top is covered using a acrylic plastic diffuser.
Louvre
Beta – double parabolic reflector louvre with side and cross-blades of satin matt metallised aluminium with excellent reflection characteristics (> 92 %), integrated into a single unit. Re-lamping is performed from the top, without removing the louvre. Earthed.
Reflector
Reflectors of specular anodised aluminium. The three lamp design has separate reflectors for direct respective indirect lighting. The reflector for indirect lighting gives wide light distribution. (1 and 2 lamp designs do not feature separate reflectors for indirect lighting.)
Emergency lighting
Some variants available with emLED.
Dimming
Most models can also be equipped with other ballasts for dimming.
Miscellaneous
The luminaire can on request be equipped in a 45/49 W design.
