Installation
Two-point suspension c/c 55–78 mm in ceiling cups for single installation. Luminaire 1 in an installation for series installation is installed using wire loops in the ceiling. Luminaires 2–5 in an installation are installed using wire loops in subsequent luminaire’s undersides. Ceiling cups for luminaires for series installation are not included, must be ordered separately. Ceiling cups are installed next to wire loops.
Connection
Snap-in terminal block 5 x 1.5 mm2, through-wiring is possible. Luminaire for continuous installation has strain relief and snap-in block at the bottom.
Design
Luminaire shades made of matt opal acrylic, screen holder made of silver-coated steel. Supplied with white fabric cord and white high gloss ceiling cup made of steel. Luminaires for series installation are supplied with separate wire and wire lock.
Max. pendant length: 3,5 m.
Dimming
DALI/phase-pulse control as standard.
LED-information
3000/4000 K: Ra (CRI) min. 80, MacAdam 3 SDCM. Driver life-time: up to 100.000 h/10 % (max failure).
Miscellaneous
A cut-out in the ceiling cup is made using cutters 94248 for a surface mounted mains cable.
