Heat-recovery ventilation unit KM

industrialcommercial

Basic parameters: Heating capacity - 0,5 — 82,2 kW Air flow - 450 — 3700 m3/h Weight - 25,9 - 57,9 kg Colour - silver Casing - steel + aluminum Short characteristic: KM mixing chamber is designed to work with fan heaters LEO . It enables delivery of fresh (outside) air into the room. Depending on the requirements, the air flow can be heated via the heat exchanger and then directed inside the building. The chamber is equipped with three air intakes: 2 of recirculation air and one of fresh air. It is possible to smoothly adjust the degree of dampers opening from 0 to 100%. Thanks to this it is possible to recover heat by recirculation. KM is available in three versions: KM S, KM L and KM XL KM with fan heater, UVO roof fans and KM REGULATION system create complete mechanical ventilation system. More information about complete heating and ventilation solutions for buildings can be found in FLOWAIR System menu. Purpose: KM with fan heaters can be applied in medium and big cubature buildings like industrial halls, warehouses, commercial halls, etc. Control system: KM REGULATION – complete control and protection set for KM + LEO Technology/innovation/benefits: Construction – modular construction (3 parts) makes possible to install the unit in various configurations. This solution gives various installation options. Casing of the heater is made of light and durable material – expanded polypropylene (EPP). Unit is in standard equipped with coarse 80% (PN-EN ISO 16890-1E) class filte installed on air inlet. Its position determines filtration of fresh air or fresh and recirculation air.
