Sliding gate XENTRY 2

foldingsteelzinc

Application Area: Product Category: Fast Folding Gates This Fast Folding Gate has a solid drive with 2 motors in the bottom of the columns and a guide trough at the top or bottom. The folding gate opens at about 1 meter per second and is TÜV certified. Application areas: Apartment complexes Industrial estate Real estate Protected trucks Parking THE ULTIMATE COMBINATION IN ONE PRODUCT: AS VANDAL-PROOF AS A SLIDING GATE AND AS EFFECTIVE AS A BARRIER This dual-motor Speedgate has a solid drive-unit at the bottom and a guide-channel at the top or bottom. The folding gate opens at approx. 1 metre per second and is TÜV certified. This Speedgate is offently used in apartment complexes and on industrial premises. 2 motors Mechanical locking Solid drivesystem at the bottom of the column Gate leaff infills are bars, double welded mesh or single-side panelling Guiderail, top or bottom Speed aprox. 1 m/sec Number of cylces per day, approx 600 Metalised and provided with a doublelayer powder coating Approved by TÜV in compliance with EN 13241-1 Integrated controls Max. width 7,000 mm Max. heigth 4,000 mm Max. 24 m² TECHNICAL SPECIFICATION SPEEDGATE XENTRY 2 Columns 2 RHS profile steel columns, 220 x 220 x 6mm with service lit. Guiding Profiled steel plate 55 x 162mm with integrated cable duct. Drive Elektromechanical with 2 motors placed in the columns, controlled by intelligent inverter to provide accurate speed control. Motors: 0,18 kW, IP54, 4 inductive proximity limit switches, 24Vdc. Protection Steel grit blasted SA 2½-3, zinc metalized 30μm, 2 layer polyester powdercoating (120μm). Standard RAL color.
