Technical Specifications
Efficiency (%) 80,0
Exhaust outlet diameter (mm) 200
Complies with Ecodesign criteria Yes
Designed for heat recovery unit Yes
Fuel type recommended seasoned hardwood with moisture ≤20%
CO emission (at 13% O 2 ) ≤ given in % 0,09
Flue gas temperature (℃) 250,0
Max log length (cm) 50
Emission of dust (mg/Nm 3) 35,0
Compliance with BImSchV 2 standard Yes
Glazing type lateral
Opening of the doors lift up, to the right
Material steel
External air inlet Yes
The liner of the combustion chamber Yes
Ashpan No
Decorative printed glass Yes
Efficient burning process & maintaining of temperature to keep the warmth for longer thanks to lining of combustion chamber with TERMOTEC - heat accumulating material which raises the temperature in the combustion chamber.
High flue and smoke tube which are transversely located - increases the area of heat echange between the insert and the surrounding. Reducing the temperature of the gas exhaust helps to increase the efficiency of the device.
Fireplace's doors resistant to tensions and stable thanks to the use of closed profile. Door seals designed in profiled canal what guarantees proper adherence and protects against ewentual falling out while operating.
Combustion of fuel particles thanks to deflector, which extends the exhaust gas path..
Triple air system of combustion chamber: primary air- directed to combustion plate; secondary air supplied by the holes located in the back wall. Additionally, the system of air clean glass has been applied (curtain air).
