Technical Specifications
Efficiency (%) 80.0
Exhaust outlet diameter (mm) 200
Complies with Ecodesign criteria Yes
Designed for heat recovery unit Yes
Fuel type recommended seasoned hardwood with moisture ≤20%
CO emission (at 13% O 2) ≤ given in% 0.10
Flue gas temperatures (℃) 255.0
Max log length (cm) 35
Emission of dust (mg / Nm 3) 32.0
Compliance with BImSchV 2 standard Yes
Glazing type straight
Opening of the doors to the left
Material steel
External air inlet Yes
The liner of the combustion chamber Yes
Decorative printed glass Yes
Proceo de combustión eficiente y temerimiento de la temperature para maintain el calor during más tiempo gracias al revestimiento de la cámara de combustión con TERMOTEC, material de acumulación de calor that raises the temperature in the cámara de combustión.
Suministro de aire desde el exterior solo gracias a la entrada de aire externa de 125 mm. Ajuste de aire with a single regulador that avoids the incorrect use.
Triple air system of fuel: primary air direction of the fuel panel; aire secundario suministrado por los orificios ubicados en la pared posterior. Además, if you have applied the limpio vidrio system (aire de cortina).
The limpieza de la cámara de combustión gracias al hogar hexagonal. Inset de chimenea sin rejilla: combustión completo en el polvo, lo que che que leña se quema en cenizas finas en una cantidad mínima. The energetic energy obtenida de la leña se aprovecha al máximo.
