Technical Specifications
Rated output (kW) 14,0
Range of heating power (kW) 7.0 - 18.0
Efficiency (%) 70,0
Exhaust outlet diameter (mm) 200
Complies with Ecodesign criteria No
Designed for heat recovery unit No
Fuel type recommended seasoned hardwood with moisture ≤20%
Weight (kg) 124,0
CO emission (at 13% O 2 ) ≤ given in % 0,61
Flue gas temperature (℃) 352,0
Max log length (cm) 45
Emission of dust (mg/Nm 3) 99,7
Compliance with BImSchV 2 standard No
Glazing type straight
Opening of the doors to the left
Material cast iron
Ashpan Yes
MAXIMUM USE OF ENERGY
Maximum use of heat due to densely spaced radiators and the wall of the insert made of high quality cast iron with a thickness of 8 mm.
Combustion of fuel particles thanks to deflector, which extends the exhaust gas path.
Increased efficiency of the insert through manual control of chimney draft by using the built-in damper.
Manual control over the combustion process carried out by ash tray regulator.
SAFETY AT THE HIGHEST LEVEL
Classic front of insert is equipped with a heat-resistant ceramics that can withstand temperatures up to 660°C.
Decorative fence helps to maintain the tidiness and protects against falling out of wood.
