Anti-corrosion coating PROLINE NE 500

protectiveindustrialfor concrete

Product overview
Phenolic epoxy with 78% volume solids, formulated for protective linings on steel and concrete. Provides anti-corrosion, chemical and mechanical resistance for steel and concrete in contact with chemical compounds, notably hydrocarbons, and under continuous immersion.

Thermal resistance
Resistant to dry heat up to 200°C and to immersion up to 100°C.

Recommended applications
Recommended for internal linings of tanks and pipelines (acids, diesel, etc.).

Recommended system

• 2 coats of 150 microns each
• Total system thickness: 300 microns

Technical sheet
Technical sheet available (protected).

Technical characteristics

• Type: Phenolic epoxy
• Volume solids: 78%
• Substrates: Steel and concrete
• Chemical resistance: Resistant, especially against hydrocarbons and in continuous immersion
• Mechanical resistance: Designed for mechanical stresses
• Thermal resistance (dry): Up to 200°C
• Thermal resistance (immersion): Up to 100°C
• Recommended coating system: 2 x 150 µm (total 300 µm)
• Typical uses: Internal lining of tanks and pipelines (acids, diesel, etc.)
