Power socket EU-USBC-12

USBdoubletriple

Description
Compact 16A flush-mounted Schuko power socket with an integrated USB‑C charger (18 W). Combines a standard grounded Type F mains outlet and a dedicated USB‑C charging port to supply mains-powered equipment while charging USB‑C devices without an adapter. Suitable for residential and commercial electrical installations where space and convenience are priorities.

Product highlights

• 16A mains socket + integrated USB‑C charger
• Fast charging up to 18 W via USB‑C
• Direct charging for smartphones, tablets and USB‑C accessories
• Reduces need for external adapters and frees a mains outlet
• Integrated child protection for safety
• Designed for standard electrical installations and simple mounting
• Flush-mounted design intended for use with glass faceplates (sold separately)

Installation & compatibility

• Compatible with round or square back boxes ≥ 40 mm depth
• Can be mounted horizontally or vertically
• For use on standard 230V electrical installations
• Connections: live / neutral / earth (screw terminals)
• Compatible devices: smartphones, tablets, USB‑C accessories and low‑power electronics

Pair it with

• Gloss or matt SR tempered glass faceplate and metal mounting frame (sold separately)
• Module combinations from 1 gang up to 4 gangs

What’s in the box

• Schuko earthed socket with integrated USB‑C charger mechanism - Type F, white
• Installation guide
• Glass faceplate and metal mounting frame sold separately

Caractéristiques / spécifications techniques

• Manufacturer: Livolo
• Reference: EU-USBC-12
• Dimensions: 45 × 45 × 38 mm
• Type: Power socket with USB‑C charger (USB Type‑C port)
• Charging power: USB‑C 18 W
• Rated current: 16 A
• Operating temperature: -10°C to +40°C
• Connection: Screw terminals
• Cable cross-section: 1.5 to 2.5 mm²
• Certification: CE & RoHS
• Permissible humidity: Up to 95%
• Stripping length: 10 mm
• Socket type: Europe (Type F)
• Material: Plastic
• Child protection: Yes
• Earthing: Yes
• Categories: Power socket
• Function: Schuko Type F with integrated USB‑C charger
