USB charger USB-AC-14

Short description
Flush-mounted USB-A + USB-C wall charger mechanism delivering up to 36 W for fast charging of smartphones, tablets and USB accessories. Designed for integration into standard electrical installations with optional glass faceplate for a refined finish.

Overview
This USB-A + USB-C charger socket (Livolo USB-AC-14) enables simultaneous charging of multiple devices without an external mains adapter. Built-in smart charge management allocates power efficiently between ports to optimise charge time for connected devices. The compact flush-mounted mechanism fits standard back boxes and pairs with glass faceplates and metal frames to suit residential and commercial interiors.

Product highlights

• Dual ports: USB-A and USB-C for simultaneous charging
• Fast charging up to 36 W total output
• Suitable for smartphones, tablets, smartwatches and USB accessories
• Intelligent automatic charge management
• Eliminates the need for external mains adapters, saving space
• Flush-mounted design for standard electrical installations
• Compatible with decorative glass faceplates (sold separately)

Installation & compatibility

• Fits round or square back boxes with depth ≥ 40 mm
• Can be mounted horizontally or vertically
• For connection to standard mains wiring (live/neutral)
• Connection via screw terminals; cable cross-section 1.5–2.5 mm²
• Compatible devices: smartphones, tablets, smartwatches, headphones, USB accessories

Pair it with

• Gloss or matt SR tempered glass faceplate and metal mounting frame (sold separately)
• Available combinations from 1-gang to 4-gang configurations

What’s in the box

• USB-A + USB-C charger socket mechanism — 36 W, white
• Installation guide
• Glass faceplate and metal mounting frame sold separately

Technical specifications

• Manufacturer: Livolo
• Reference: USB-AC-14
• Dimensions: 45 × 45 × 35 mm
• Type: Flush-mounted wall charger mechanism
• Operating temperature: -10°C to +40°C
• Connection: Screw terminals
• Cable cross-section: 1.5 to 2.5 mm²
• Certification: CE & RoHS
• Maximum power: 36 W
• Permissible humidity: up to 95%
• Stripping length: 10 mm
• Material: Plastic
• Ports: USB-A + USB-C
• Category: Network and multimedia
• Function: USB-A + USB-C charger
