Multimedia electrical socket holder A-C1/SR-12M

Short description Elegantly finishes a 1-button touch switch and a fittings mechanism with a glass faceplate that provides a modern, harmonious wall integration.

Overview Bring a clean, durable finish to electrical installations with the Livolo glass faceplate A-C1/SR-12M. Designed to combine a 1-button touch switch and a fittings mechanism (power, network or multimedia), this double faceplate optimises wall space while maintaining a consistent visual line. Colour is applied behind the glass to prevent fading and preserve appearance over time.

Product highlights

• Mixed configuration: 1-button touch switch + fittings module
• Tempered glass construction for scratch and wear resistance
• Flat modern profile for flush wall integration
• Colour applied behind glass for lasting finish
• Enables modular wall combinations with other faceplates
• Quick installation with precise alignment

Installation & compatibility

• Compatible with 1 one-button touch switch + 1 fittings mechanism
• Mounts on C7-MF metal mounting frame
• Compatible with round or square back boxes ≥ 40 mm
• Can be mounted horizontally or vertically

Pair it with

• All 1-button touch mechanisms, sockets and multimedia modules
• Mechanisms and modules sold separately

What's in the box

• Glass faceplate 1 button + 1 gang
• C7-MF metal mounting frame
• Mechanism sold separately

Technical specifications

• Manufacturer: Livolo
• Reference: A-C1/SR-12M
• Dimensions: 151 × 80 × 4 mm
• Type: Double faceplate
• Certification: CE & RoHS
• Material: Tempered glass
• Configuration: 1 circuit + 1 gang
• Categories: Faceplate
• Number of gangs: 2
• Layout: 1 button + 1 gang
• Weight: 0.184 kg
