Flexible LED light strip LUMARIS

Overview
Intelligent lighting starts with Lumaris, bringing tunable white and warm dim technology to accent and cove lighting applications. This 2-channel LED tape light combines incandescent-like dimming with precise color temperature control, delivering smooth transitions from an incandescent glow to bright white (1,800K–4,000K) with flicker-free dimming down to 0.1%. Modular three-piece design simplifies installation and programming compared to other DMX and 0-10V tunable white tape solutions. Field-cuttable every 2 inches (50 mm), 10 mm wide, installs with strong VHB adhesive backing and fits straight and curved applications. Available in 16.4 ft and 98.4 ft reels with plug-in and hard-wired power supply options. Designed to work with Lutron HomeWorks, RadioRA 3, Athena, and myRoom XC wireless control systems.

Highlights

• 2-channel tunable white light with consistent 90+ CRI across 1,800K–4,000K
• Incandescent-like dimming plus precise color temperature control
• 200 lumens per foot of accent illumination suitable for cove, under-cabinet, and architectural details
• Field-cuttable every 2 inches with strong VHB adhesive backing for dry/damp indoor locations
• Modular three-piece design to simplify installation and programming
• Tunable White Controller supports up to 16.4 ft of tape; Multi-Channel Controller supports up to 49.2 ft
• Designed to work with Lutron wireless control systems via Clear Connect Type X technology

Light Engine
2-channel tunable white light; 1,800K–4,000K; 90+ CRI

Wireless Control
Clear Connect – Type X wireless communication (works with Lutron HomeWorks, RadioRA 3, Athena, myRoom XC)

Dimensions & Mechanical
.47 in (12 mm) width; available lengths: 16.4 ft and 98.4 ft (5–30 m); field cuttable to 2 in (50 mm) segments

System Compatibility

• HomeWorks
• RadioRA 3
• Athena
• myRoom XC

Performance Specifications
Light Engine: 2-channel tunable white
CCT Range: 1,800K–4,000K
Saturated Colors: N/A
Color Rendering: 90+ CRI from 1,800K to 4,000K
Rated Life: 50,000 hours
Dimming Range: 0.1%–100%
Delivered Lumens: 200 lumens per foot

Electrical Specifications
Power Consumption: 96 W
Voltage: 120 V~ / 277 V~ 50/60 Hz
Current: 800 mA

Mechanical / Installation Options
Terminal block or flying leads; strong VHB adhesive backing; fits into a variety of aluminum extrusion profiles for architectural installations

Certifications & Warranty
Environmental & regulatory: cULus Listed for USA and Canada; FCC Part 15 Class B compliant; ICES-005 compliant
Certifications: Meets UL® 8750 / CSA C22.2 No. 250.13-14 (LED equipment for lighting products)
Warranty: 5 year limited warranty

Technical specifications

• Product family: Lumaris
• Form factor: 10 mm wide LED tape light, field-cuttable every 2 in (50 mm)
• Light channels: 2-channel tunable white
• CCT: 1,800K–4,000K
• Color Rendering: 90+ CRI
• Brightness: 200 lumens/ft
• Dimming: 0.1%–100% (flicker-free down to 0.1%)
• Rated life: 50,000 hours (L70)
• Lengths available: 16.4 ft and 98.4 ft reels
• Power: 96 W (total power consumption as listed)
• Voltage: 120 V~ / 277 V~ 50/60 Hz
• Current: 800 mA
• Control protocol: Lutron Clear Connect – Type X (native integration with Lutron wireless systems)
• Installation: VHB adhesive backing; use with aluminum extrusions; terminal block or flying leads
• Ingress / location: Indoor dry/damp locations
• Certifications: cULus, FCC Part 15 Class B, ICES-005; meets UL 8750 / CSA C22.2 No. 250.13-14
• Warranty: 5 year limited
