Stone paver PAFH5

for outdoor useflamedstone look

DESCRIPTION
Pavers 12×30
FLAMED STONE APPEARANCE
Unit of sale (U) = m²
equivalence: 1 m² = 27 pavers
Geometric specifics dimensions (cm):
length: 30
width: 12
thickness (cm): 8
weight (kg/m²): 152
Packaging (m²/pal): 7.6 (non-returnable pallet 110×90)

MECHANICAL SPECIFICATIONS

• breaking by splitting (MPa): 4
• water absorption: < 6%
• frost/thaw resistance: 0.2 kg/m²
• slip resistance: average 54

STANDARDS
NF – EN – 1339
Fascicle 29 of 30 May 2021
NF – 98 335

INSTALLATION

• Instructions provided by standard NF P 98 335 and Fascicle 29 of the CCTG prevail.
• Installation must be carried out between +5°C and +30°C on a sound substrate.
• Mortars are prepared or supplied as work progresses.
• The bedding mortar layer is levelled with a screed and applied progressively. Its thickness should be as uniform as possible (~4 cm).
• Slabs must be moistened, especially in hot weather.
• When laying, mix products of different colours and batches to ensure uniform appearance.
• Joints are left between slabs; joints are filled with mortar no sooner than 24 h and no later than 72 h after laying.
• Joint width: as small as possible but not less than 5 mm.
• The surface must be cleaned immediately after jointing to avoid residues or films on the slabs.
• Expansion joints must be provided according to normative requirements (10 m linearly or 20 m²).

MAINTENANCE

• Products are designed to reproduce natural surface aspects; original colours are very stable.
• Minimum maintenance is required; natural patina develops over time.
• Application of a mineralising treatment will ease cleaning and extend the life of the original surface appearance.
• Use of high-pressure cleaners or acidic products is discouraged due to possible alterations.
• De-icing salts should be used sparingly, avoiding stagnant excess residues.

APPEARANCE
Flamed stone appearance

Characteristics / technical specifications

• Unit of sale: m²
• Equivalence: 1 m² = 27 pavers
• Length: 30 cm
• Width: 12 cm
• Thickness: 8 cm
• Weight: 152 kg/m²
• Packaging: 7.6 m²/pallet (non-returnable pallet 110×90)
• Breaking by splitting: 4 MPa
• Water absorption: < 6 %
• Frost/thaw resistance: 0.2 kg/m²
• Slip resistance: average 54
• Standards: NF – EN – 1339 ; Fascicle 29 of 30 May 2021 ; NF – 98 335
