Anodized aluminium body
Inox/black color with anticorrosive and decorative propertiesh
Overvoltage protection
Increases the immunity of the luminaire to electrical discharges up to 15 pulses at 10 kV
Open / close the hinge luminaire for ease of installation and service
Osram 4DIM driver
High-performance, constant current and programmable
Available functions:
- adjustable output current
- programmable time programs
- temperature control on the module
- power regulation of the luminaire with output voltage
- maintain constant light output over time
Replaceable LED module
Waterproof LED module. Equipped with 48 LEDs, available in 8 optical circuits
Lamp diffusser
Transparent cone shaped (PMMA), dedicated to OW LED luminaire
Application: urban roads, residential roads (internal), parkings, pedestrian crossings
Assembly: on extension arms, wall brackets, columns with extension arms with ø60x50 mm ending
Ingress protection: IP 66
Material: body and cap – anodised aluminium formed sheet metal
Colour: black
Optical system: PMMA optics, interchangeable LED module
Number of LEDs: 48 for 144W, 96W, 120W
Expected useful lifetime: L90F10 – 50 000h, L80F20 – 100 000h
CRI: >70 for 5000K, 4000K; >80 for 3500K, 2700K
Input voltage frequency: 50/60Hz
Power factor: ≥0.95
Inrush current: : 80A / 175µs for 144W, 96W, 120W; for 120W
