Rectangular glass brick

roundsquaresandblasted

Description
From small to large-format glass blocks, suitable for creating original partitions and architectural compositions by combining different dimensions.

General characteristics

• Standard European format: 19 x 19 x 8 cm.
• Various sizes and thicknesses available (see detailed dimensions).
• Finishes: clear glass; available smooth, corrugated (Cortina) or sandblasted.
• One face can be lacquered in a wide range of colours.
• Installation: traditional masonry laying.

Dimensions
5 cm thickness (19 × 19 cm blocks)

• Allow thinner, lighter interior partitions.
• Available models: corrugated, Cortina.

30 × 30 × 10 cm blocks

• Large format for expansive walls.
• Glass: smooth, corrugated, grid-patterned or frosted.
• Indicative weight: 7.5 kg.

24 × 24 × 8 cm and 24 × 11.5 × 8 cm blocks

• Indicative weights: 3.8 kg (24×24×8) and 2.1 kg (24×11.5×8).

11.5 × 11.5 × 8 cm blocks

• Indicative weight: 1.1 kg.
• Ideal for random inserts in a partition or to fill niches during renovation.
• Available in smooth, corrugated or sandblasted finishes.

Round blocks

• Orbis: diameter 19 cm — available as single-shell (5 cm thickness) or double-shell (10 cm thickness). Indicative weight: 2.9 kg.
• Round paver: diameter 11.5 cm, hollow, 6 cm thickness; usable vertically or horizontally (floor installation possible).
• Decorative tip: possible to glue a glass or plexiglass disc on the hollow face to add colour.

Applications

• Counter
• Shower partition
• Room divider
• Façade
• Indoor and outdoor use

Colours
■ Clear

Technical characteristics / specifications

• Standard format: 19 x 19 x 8 cm (European format reference).
• Available thicknesses: 5 cm, 8 cm, 10 cm (depending on model and type: single-shell, double-shell).
• Available sizes: 30×30×10 cm; 24×24×8 cm; 24×11.5×8 cm; 11.5×11.5×8 cm; round Ø19 cm (Orbis); round paver Ø11.5 cm (hollow).
• Indicative weights: 30×30×10 = 7.5 kg; 24×24×8 = 3.8 kg; 24×11.5×8 = 2.1 kg; 11.5×11.5×8 = 1.1 kg; Orbis Ø19 = 2.9 kg.
• Finishes: clear glass, smooth, corrugated (Cortina), grid-patterned, frosted, sandblasted.
• One-face lacquering option in many colours (aesthetic option).
• Recommended installation: traditional masonry laying.
• Applications: partitions, walls, counters, showers, façades; suitable for indoor and outdoor installation.
