Glass wool suspended ceiling FOCUS™ DS
tileacousticinsulating

glass wool suspended ceiling
glass wool suspended ceiling
glass wool suspended ceiling
glass wool suspended ceiling
glass wool suspended ceiling
glass wool suspended ceiling
glass wool suspended ceiling
Add to favorites
Compare this product


Characteristics

Material
glass wool
Configuration
tile
Technical characteristics
acoustic, insulating
Thickness

20 mm (0.8 in)

Width

600 mm, 1,200 mm (24 in)

Length

Max.: 2,400 mm (94 in)

Min.: 600 mm (24 in)

Description

For applications where a suspended ceiling with a concealed grid is required, but individual tiles must be easily demountable. Ecophon Focus™ Ds has a concealed grid and symmetrical edge design, allowing easier assembly, integration of light fittings and ventilation. The ceiling has an even appearance, with the bevelled edges forming a discreet groove between the tiles. The tiles are easily demountable. The systems consist of Ecophon Focus™ Ds tiles and Connect™ grid systems, with an approximate weight of 3-4 kg/m² (4-5 kg/m² with Ecophon Extra Bass). The tiles are manufactured from high density glass wool. The visible surface has an Akutex™ FT coating and the back of the tile is covered with glass tissue. The edges are painted.To improve absorption in the low frequency range, Ecophon Extra Bass can be installed on top of the suspended ceiling. For best performance and system quality, use Connect™ grid and accessories. The grid is manufactured from galvanized steel. The system is patented. Grids/Profiles: T24 Installation diagrams: M206, M208, M394, M400 Additional systems Ecophon Focus™ FriezeEcophon Focus™ Fixiform Ds,Ecophon Focus™ Wing,Ecophon Focus Edge™ 500,Ecophon Focus™ Ds level change, Akutex™ FT-A modern surface available in many colours and for most products. The Akutex™ FT surface in combination with the glass wool core provides optimal sound absorption. Compared to Akutex™ T, the average pore size is less than half, with the number of pores being doubled, but the superior acoustic properties are still retained. With the smaller pores, the product is even more dirt repellent, making the surface easier to clean.
