For applications requiring a ceiling which is mechanically secured to the structural soffit. Ecophon Focus™ F is installed directly to an existing plaster ceiling, boarding, battens or concrete, creating a ceiling with a smooth appearance. The bevelled edges create a narrow groove between each tile. The tiles are not demountable. The tiles are manufactured from high density glass wool. The visible surface has an Akutex™ FT coating and the back of the tile is covered with glass tissue. The edges are reinforced and painted. The weight is approximately 2,5 kg/m². Ecophon recommend Connect screws for a quick and secure installation.
Installation diagrams: M15
Akutex™ FT - Edge F-
The Akutex™ FT surface in combination with the glass wool core provides optimal sound absorption. Compared to Akutex™ T, the average pore size is less than half, with the number of pores being doubled, but the superior acoustic properties are still retained. With the smaller pores, the product is even more dirt repellent, making the surface easier to clean.
