Fixed shower screen POLARIS SUPER

swingcornertempered glass

Description
Corner shower enclosure composed of a hinged door with two inline fixed panels plus an additional fixed side panel. The door can open both inward and outward. Designed to accommodate larger dimensions compared with a standard shower door, suitable for projects requiring wide access and versatile opening.

Profiles

• Matte Carbon "L63"
• Brushed Nickel "SNK"
• Matte Mauve "L64"
• Matte Ice "L90"
• Matte Black "L96"
• Matte Sage "L73"
• Brushed Gold "GLB"
• Matte Sky "L65"
• Brushed Bronze "AL4"
• Matte Navy Blue "L92"
• Matte Taupe "L99"
• Matte Sand "L98"
• Matte Lead "L80"
• Matte White "L91"
• Polished Gloss "ULU"
• Matte Linen "L70"

Tempered glass panels

• Grey Transparent Glass "TG"
• Extra Clear Glass "TE"
• Transparent Glass "TR"
• Grey Satin Glass "GS"
• Mirror "SY"
• Satin Band H.100 "RF"
• Patterned Glass "ST"
• Satin Glass "AS"

Documentation available (download)
Product sheet; Installation instructions; Spare parts; Fixed wall spare parts.

Size chart - Door
Item | Adjustable range [cm] | Opening [cm]
B2950 | 97-99 | 53.6
B2951 | 102-104 | 53.6
B2952 | 107-109 | 58.6
B2953 | 112-114 | 58.6
B2954 | 117-119 | 61.6
B2955 | 127-129 | 63.6
B2956 | 137-139 | 73.6
B2957 | 147-149 | 73.6
B2958 | 157-159 | 73.6
B2959 | 167-169 | 79.8
B2960 | 177-179 | 86.6

Size chart - Fixed wall
Item | Adjustable range [cm] | Opening [cm]
B3000 | 67-69 | //
B3001 | 69-71 | //
B3002 | 72-74 | //
B3003 | 74-76 | //
B3004 | 77-79 | //
B3005 | 79-81 | //
B3006 | 82-84 | //
B3007 | 84-86 | //
B3008 | 87-89 | //
B3009 | 89-91 | //
B3010 | 97-99 | //
B3011 | 99-101 | //
B3012 | 107-109 | //
B3013 | 109-111 | //
B3014 | 117-119 | //
B3015 | 119-121 | //

Features / Technical specifications

• Brand: SAMO
• Commercial name: POLARIS Super
• Type: hinged door with two inline fixed panels + fixed panel, corner configuration
• Door opening: both inward and outward
• Panels: tempered glass with available variants (transparent, extra clear, satin, patterned, mirror, satin band)
• Profile finishes: multiple color/finish options (e.g. L63, SNK, L64, GLB, AL4, L92, etc.)
• Sizes and item codes: see size charts above
• Technical documentation available: product sheet, installation instructions, spare parts lists
