Water-cooled chiller AG042FAVANGEU

air/water cooledrooftopcompact

Overview
The Samsung HVM R32 provides efficient cooling and heating using R32 refrigerant with a significantly lower GWP than R410A. Its compact footprint and moderate weight simplify transport, rooftop placement and installation while delivering reliable performance across a wide ambient and water temperature range.

Key Features

• Lower GWP: Uses R32 refrigerant (GWP = 675) and requires a smaller refrigerant charge compared to R410A systems.
• Enhanced low-temperature heating: Capable of leaving water temperatures up to 60°C, up to 5°C higher than comparable R410A systems.
• Compact transportable design: Footprint 1.38 m² and net weight approx. 425–433 kg, enabling transport in a 1‑ton truck, use of cargo elevators and rooftop installation.

Additional information / disclaimers

• GWP comparison example: R32 GWP = 675; R410A GWP = 2088. Example refrigerant charge impacts: R32 13.8 kg → 9.32 tCO2e; R410A 18 kg → 37.58 tCO2e.

Technical specifications

• Brand: Samsung
• Product name: HVM R32
• Model / commercial designation: AG042FAVANGEU (also referenced as AG042FAVANG/EU; outdoor unit AG042FAVANG/EU)
• Type: DVM chiller (heat pump)
• Available capacity: 42.0 kW (cooling / heating)
• Power supply / phases: 3 phases (3,4,380-415,50/60)
• Performance (nominal): 15 HP
• Power input: Cooling 12.35 kW; Heating 11.83 kW
• Current input: Cooling 20.5 A; Heating 19.9 A
• Power ratings: MCA 32.00 A; MFA 40.00 A
• Energy efficiency: EER (cooling) 3.40 W/W; COP (heating) 3.55 W/W
• Fan: Propeller type; Motor output 630 W × 2; Air flow (cooling) 314 CMM; External static pressure (Min/Std/Max) 8.0 mmAq
• Water-side heat exchanger: Brazed plate; Quantity 2; Water flow rate (Cooling / Heating) 120 / 120 LPM; Pressure drop (nominal) 60 kPa; Max operating pressure 1.0 MPa; Connection type: Flange; Pipe connection (inlet/outlet) 40 A
• Field wiring: Transmission cable 0.75–1.5 mm²
• Refrigerant: R32 (fluorinated greenhouse gas, GWP = 675); factory charge 13.80 kg (example tCO2e 9.32)
• Sound pressure level: 55.0 dBA
• Outdoor unit dimensions / weight: Net dimensions (W×H×D) 1,795 × 1,695 × 765 mm; Net weight 425 kg (installation note references approx. 433 kg)
• Operating water temperature range: Cooling 5–25 °C; Cooling (with brine) -10–25 °C; Heating 25–60 °C
• Operating water flow range: 60–240 LPM; Minimum water storage in system 294 L
• Operating ambient temperature range: Cooling -15–48 °C; Heating -25–43 °C
