Solar control glass panel ŞIŞECAM TENTESOL TITANIUM

insulatinglaminatedtempered

Şişecam Tentesol Titanium Grey

• Prevents solar heat transmission into buildings, controls the luminance of sunlight and provides a comfortable working and living environment.
• Reduces cooling energy consumption and delivers savings on cooling costs.
• Due to its coating, the substrate glass color is rendered more clearly.
• Creates a mirror effect from the brighter side of light: provides one-way view from inside to outside during daytime and from outside to inside at night.
• With high reflectance, Şişecam Tentesol Titanium offers a uniform external appearance for curtain-wall buildings by masking background features such as spandrels, columns, beams and suspended ceilings.
• The coating can be applied on surface 1 (outside) or surface 2 (inside) of Insulating Glass Units. Surface 1 emphasizes reflectance; surface 2 emphasizes color.
• Long-term durability due to its hard coating.
• Can be toughened, heat strengthened and bent. Lamination and enameling are also possible.
• Produced on a project basis.

Areas of Use
Şişecam Tentesol Titanium is primarily intended for facades and windows of commercial buildings, balcony glazing, and interior architectural solutions such as partition walls and decorative applications. It can be used as monolithic glass or within Insulating Glass Units (IGU). Solar control glass is susceptible to thermal breakage; to avoid this risk, toughening or heat strengthening is recommended. When laminating Şişecam Tentesol Titanium, all panes in the laminated unit should be either toughened or heat strengthened to avoid thermal breakage.

Production Method
Şişecam Tentesol Titanium is manufactured by applying a thin, reflective and highly durable metal oxide coating onto clear or tinted float glass.

Size and Thickness
Thickness (mm): 6.0 & 8.0
Standard sizes (mm): 3210×2250; 3210×2500; 3210×6000
Thickness tolerances (mm): ±0.2 for 6.0, ±0.3 for 8.0
Nominal size tolerances: ±5 mm. Please consult Şişecam for non-standard size and thickness requests.

Quality
Şişecam Tentesol Titanium is manufactured in accordance with EN 1096 "Glass in Building - Coated Glass".

Technical characteristics / specifications

• Light Transmittance: <40
• U Value: >1
• Solar Factor: 30>x≥20
• Tempered: Yes
• Shading Coefficient: 40>x≥30
• Thickness options: 6.0 mm and 8.0 mm
• Standard sizes (mm): 3210×2250; 3210×2500; 3210×6000 (nominal size tolerance ±5 mm)
• Thickness tolerances: ±0.2 mm (6.0 mm), ±0.3 mm (8.0 mm)
• Manufacturing: metal oxide reflective coating with hard coating on float glass
• Mechanical treatments possible: toughening, heat strengthening, bending; lamination and enameling possible (for lamination all panes should be toughened or heat strengthened to avoid thermal breakage)
• Standard: EN 1096 (Coated Glass)
• Produced on a project basis; coating may be applied on surface 1 (outside) to emphasize reflectance or on surface 2 (inside) to emphasize color
