Digital timer SA-027 series

standardprogrammable

365-Day Annual Timer The ENFORCER SA-027HQ Annual Timer can be programmed to operate two relays 24 hours a day, over the course of an entire year. These relays can be used to control devices in many applications such as security, access control, lighting, and environmental control. The two Form C relays can each be programmed to operate in shunt or momentary mode for up to 50 unique events. Each event can be programmed on a weekly or daily schedule. Block programming allows events to be repeated on consecutive days. 10 Programmable holidays disable the timer for a single day, or for the same day every year. FEATURES * Two N.O. or N.C. Form C relays 10A@14VDC. * Each relay can be programmed for 50 events, for a total of 100 individual programmable events. * The 100 programmable events can be set weekly, daily, or hourly, over the course of an entire year. * Block programming allows events to be repeated on consecutive days. * 10 Programmable holidays. * Event outputs can be programmed disable, ON, OFF, shunt, or momentary (1~99 seconds). * Can be programmed for password protection. * EEPROM protects memory loss when power failure. * Built-in clock backup battery. * Built-in backup battery charger for external backup battery use. * Compensates for leap years. * Can be set for Standard or Daylight Saving Time. * Alphanumeric backlit LCD display for easy programming.
