Motion detector THEPIXA P360 UP WH

presencetemperaturebrightness

**Currently not available** Optical sensor for ceiling installation KNX Data Secure Rectangular detection area with up to 6 flexible detection zones (Total area 11.0 x 15.5 m │171 m2; at 4.5 m installation height) Restriction of the detection area via app (thePixa Plug) Automatic presence and brightness-dependent control for lighting and HVAC Each detection zone has its own light measurement Adjustment of brightness measurements via thePixa Plug app Configurable sensitivity of sensor Distinction between motion and presence Parallel switching of multiple sensors (Master/Slave or Master/Master) Test mode for checking function and detection area via app (thePixa Plug) Output of occupancy rate and occupancy density via telegram Integrated temperature sensor Ceiling installation in flush-mounting box (2-point fixing) Surface mounting on ceilings possible with surface frame (option) thePixa Plug app for settings and evaluations (iOS/Android) KNX firmware update possible (ETS app) Sensor firmware update possible (thePixa Plug app) 6 channels light, Z1 light – Z6 light: Switching or constant lighting control with 6 independent control systems and standby function (orientation light) Switching mode with dimmable lighting Free switch object with configuration type switching Fully or semi-automatic device Brightness switching value configurable in lux by using parameters Brightness switching value configurable in lux by using parameters and telegram Light time delay configurable by using parameters Aura effect for better orientation and greater safety Manual override by telegram 6 channels HKL, Z1 HKL – Z6 HKL: Configurable switch-on delay and time delay Sending of operating mode
