Hanging pergola S3

extruded aluminumwith mobile slatssun shade louvers

CUSTOM-BUILT BIOCLIMATIC ALUMINUM S3 PERGOLA BETWEEN WALLS ELECTRIC PARALLEL SLATS Max. projection: 6029mm Max. width: 4000mm Unlimited total width in several modules - Extruded aluminum structure - Unlimited choice of universal RAL structure colors - Extrusion thickness: 2 to 3 mm (depending on profile) - 190x28 mm double-wall extruded aluminum slats with 2 reinforced central partitions - Slat rotation 0° to 105 - Load-bearing capacity 50kg/m² - i.e. 800kg/16m². - Blades + Structure with integrated seals - Feet 120 x 120 mm, height 2500 mm (can only be cut with visible plate) - Blade mounting by clipping system - Concealed jack motor with multi-channel remote control - Ground mounting bracket for post (if required) - Installation between walls - Stainless steel screws - Box wall mounting - Tilt angle: 0 - Water drainage through support beam - Approximate weight for a 4.5 x 6 m pergola +/- 630 kg - Wind rating: Class 6 UNE EN 16561 - European manufacturing - 10-year warranty - Free delivery in mainland France - Indicative delivery time 8/10 weeks
