Several air discharge options
Simple to control
Long lifetime
Suitable for various locations
Low investment
horizontal or vertical air discharge
extra louvres available
4-way or 6 way down flow plenum for suspended ceilings
on/off thermostat control
5-step switch regulates air volume (optional)
suitable for all water temperatures (not steam)
Heat emission
0kW - 11.7kW
Air volume
0m³/h - 1400m³/h
Max. throw horizontal
10m
Max. throw vertical
3.5m
Connection voltage
230V - 230V
Number of phases
1
Nominal current
0.3A
Max. electric power input
79W
Adjustable fins on exhaust side
Yes
Heat exchanger material
Aluminium/copper
Fan type
Axial
EC ventilator as standard
No
Sound pressure level at height of 5 metres
0dB(A) - 50dB(A)
Height
505mm
Width
505mm
Depth
380mm
Nominal inner diameter
3/4 inch (20)
Water-side resistance at dT 20°C
2kPa
Max. operating pressure
500kPa
Water content
0.6l
Weight including filling
20kg
Protection class
IP54
