Characteristics

Type
surface-mounted, recessed
Light source
LED
Shape
rectangular, high
Protection class
IP65
Application
for clean rooms
Material
tempered glass facing, steel
Color
white, black, blue, green
Style
contemporary
Dimmable
dimmable
Number of lights
multiple
Other characteristics
sensor
Height

100 mm
(4 in)

Length

598 mm, 623 mm, 1,198 mm, 1,248 mm
(24 in, 25 in, 47 in, 49 in)

Width

298 mm, 311 mm, 598 mm, 623 mm
(12 in, 12 in, 24 in, 25 in)

Power

37 W

Luminous flux

4,590 lm

Color temperature

Max.: 6,500 K

Min.: 2,700 K

Color rendering index (CRI)

80 unit

Description

Housing made of welded black steel, with white, antistatic powder coating (resistant to oil vapors, chemical substances, disinfectants, and cleaning agents) Specially developed MPO+ microprismatic optic designed to deliver high efficiency and standards-compliant glare-control UGR < 19 LED service life: 50000 h before luminous flux is reduced to 90 % of the initial value Chromaticity tolerance between multiple luminaires of up to 3 MacAdam ellipses Cover made of 4mm heat-treated safety glass (ESG) to reduce probability of spontaneous breakage Certified by the Fraunhofer Institute – Suitable for use in clean rooms of cleanliness class 1 to 9 as per DIN EN ISO 14644-1. Complies with GMP (Good Manufacturing Practice) regulations CL2 supreme antistatic coating was classified according to ISO 4628-1 and VDI 2083 Part 17 with overall ''excellent'' result for chemical resistance (Always check the certificate for more details) Always check in advance the suitability of the cleaning conditions and cleaning agents used Luminaire pre-wired using halogen-free leads My Product variations include: various CCT options, tunable white, asymmetric beam (MPA), Emergency, Casambi, BM Link as a standalone or in combination with a microwave sensor, and a microwave sensor as stand alone or in a corridor function set up.
