Contemporary wall light AMPHIBIAindoorPMMApolycarbonate
Add to favorites
Compare this product
Characteristics
- Style
- contemporary
- Interior/exterior use
- indoor
- Material
- polycarbonate, PMMA
- Diffuser shape
- cylindrical
- Applications
- for wet rooms, industrial, for factory
- Light source
- LED
- Number of lights
- single
- Protection class
- IP66
- Color
- white
- Other characteristics
- waterproof
- Length
Max.: 1,600 mm
(63 in)Min.: 1,100 mm
(43 in)- Color temperature
Max.: 6,500 K
Min.: 3,000 K
- Color rendering index (CRI)
Max.: 100 unit
Min.: 80 unit
Description
Product family
Amphibia – IP66 LED moisture-proof luminaires
Overview
Key features
Beam types / Visual performance
Design and Light Technology
Technical specifications
Amphibia – IP66 LED moisture-proof luminaires
Overview
- IP66 LED moisture-proof luminaire family designed for mechanically demanding and chemically aggressive environments.
- Provides combined direct and indirect light distribution using LED modules with diffused primary optics.
- Offers visually functional coverage and multiple beam distributions to meet different visual tasks in industrial, logistics and food-processing areas.
Key features
- Mechanically resistant construction using impact-resistant materials and a compact design.
- Wide operating ambient temperature range: -40°C to +54°C.
- Material options: PMMAplus, CHEMO or PC for resistance to acids, lyes, halogens, solvents, greases and oils.
- Dirt-repellent and easy to clean thanks to the drip-edge effect (incline > 15°), InvisiClick connection technology, smooth surfaces and rounded edges.
- Certified variants (Amphibia PM and Amphibia CHEMO) available for the food industry, designed for frequent cleaning and high chemical resistance.
Beam types / Visual performance
- Narrow Beam (NB) – narrow-beam distribution directing high luminous intensity from up to eight metres into shelving zones and onto the floor.
- Medium Beam (MB) – medium-beam emission optimized for rooms 4–6 m high (production and logistics).
- Wide Beam (WB) – wide-beam distribution for uniform illumination of production areas, shelving and corridors, suitable at low mounting heights.
- Asymmetric Beam (AB) – asymmetric distribution with high vertical luminous intensity to improve visual comfort in rooms up to 4 m high.
Design and Light Technology
- LED modules with diffused primary optics to ensure uniform glare-controlled lighting.
- Configurable combination of direct and indirect light to meet specific visual and comfort requirements.
Technical specifications
- Length: 1100 mm | 1600 mm
- Materials: PMMAplus | CHEMO | PC
- Light distribution: Narrow Beam | Medium Beam | Wide Beam | Asymmetric Beam
- Colour temperature: 3000 K | 4000 K | 6500 K
- Colour rendering: Ra > 80
- Glare limitation: UGR < 22
- Luminaire efficiency: Up to 175 lm/W
- Degree of protection: IP66
