- Holding Force:
. each magnet = 400 kg (P400RN)
. 2.5 & 3m versions 800 kg (BO800RN) or 1200 kg (BO1200RN)
. 400mm version 400 kg (PBO400RN) or 600mm
version 800 kg (PBO800RN)
- Voltage: 12 VDC / 24 VDC
- Current draw per magnet:
560 mA (at 12 VDC), 270 mA (at 24 VDC)
- Temperature range:
. 20°C to +70°C
- Satin Anodised Aluminium standard, option of RAL
(colour specified)
- Each handle comprises 2 elements: 1 handle
for armatures and 1 section for locks
- Wider fixing section (60mm), with profiled cover
plate to match handle
- Completely hidden fixings/connections
providing high resistance to vandalism (HRV)
- Aluminium end caps for handle and section.
|
|
- 75MM body electric strike
- Non-handed
- Adjustable jaw roller, which allows up to 4MM adjustment
between the strike of the door lock (once installed)
- Built-in varistor
- 8V - 12V - 24V DC or AC option (specify)
- Consumption in fail secure:
. 460mA @ 8V DC
. 380mA @ 8V AC
. 630mA @ 12V DC
. 540mA @ 12V AC
- Consumption with fail secure version-continious
duty model:
. 380mA @ 12V DC
. 190mA @ 24V DC
- Consumption in fail safe version: (SIR only):
. 200mA @ 12V DC
. 100mA @ 24V DC
|
|
|
|
|
|
- Mechanical Features
- Deadlocking with a patented mechanism from CDVI
- Spinning bolt to prevent sawing
- Stainless steel bolt
- Fully sealed body: Protects parts from dust
- 3MM strike plate and face plate
- Stainless steel bolt guide
- Reduced size for an easy installation
- Fail safe or Fail secure lock (adjustable) Electronic Features
- Protected against interferences: lock operated
by a powerfull solenoid with double coil without
power switching
- Interlocking function
- Built-in electronic board
- Lock status (bolt position) monitoring done
by opto-switch optical sensors (lock throws bolt
continually until locking or the alarm is activated)
- Cable for wiring (input voltage, Digicode®, push button,
alarm, etc) alarm output and door status = logic
output/open collector
- Locking and unlocking time outputs easy to set
- Input voltage: 12V DC
- Consumption in fail secure mode:
. standby: 270mA
. In rush current: 2.6A
- Consumption in fail safe mode:
. standby 270mA
. In rush current: 2.6A
|
|
- 1500Kg holding force in shear
- Self alignment
- Monitored
- Aluminium/steel finish
- 12 or 24V DC selectable voltage
- Consumption:
. 600mA @ 12V DC
. 300mA @ 24V DC
|
|
- 433.92 MHz frequency
- Capacity up to 10 remote transmitters
- 1 Remote transmitter included
- 4-channel remote transmitter
- Voltage 12V DC
- Consumption: 500mA
|
|
Onity INTEGRA Electronic Locking System
Integra manages up to 65,000 doors, 65,000 active card holders, and an unlimited number of buildings without costly wiring. Information about who can go where and when is stored in the lock, therefore, you can manage the entire flow of people from one computer or on a network.
It works with any standard, hi-co, three track, magnetic stripe card, including ID cards.
The Integra3 Features Off-line Installation
The Onity electronic locking system, called INTEGRA, manages up to 65,000 doors, 65,000 active card holders, and an unlimited number of buildings without costly wiring.
|
|
This is a heavy duty keyless digital lock with full size lever handles, allowing use as the primary lock on most doors, perticularly in high traffic situations.
The 5000 model is a stylish, contemporary design, ideal for a wide range of heavy duty entry control applications.
The Piezo actuator, used for the first time in a stand alone electronic lock provides a battery life of over 500,000 operations (approximately ten times more than a typical electronic push button lock).
-A simple and cost effective access solution.
-500,000 Operations from 4 x AA cells, batteries included.
-Easy installation and programming
-90 different user codes
-Reliable - Solid state Piezo technology, with low component count
-Durable - Tested to over 1,000,000 cycles @ 2.4 Nm
-Weather resistant Physical Vapour Deposition finish
-Remote push button and Emergency Alarm release connections
|
|
ORACODE 660 E & F
Oracode 660 M lock is easy to use. To access their room, guests simply enter their unique code into the keypad and the lock gives both visible and audible signals that it's open. If they wish, guests can also use the keypad to change the original 6-digit code to a code they find easier to remember.
Stand-alone electronic locking system
Satin chrome finish
American or European mortise
Visible and audible feedback
3 batteries (1.5 V alcaline)
Low battery indicator alerts staff
6-digit pushbutton code
Personalization of code
500-event audit trail
Emergency access with infrared communication link via a psion
Programming options:
- allows for limited card access to staff in restricted areas
- activates the lock in passage mode
|
|
ORACOD Expert
The Oracod Expert is an exterior keypad for hotel entrances or parking, connected online with Oracode system installation.
|
|
The Codelocks keyless electronic locks represent a major step forward in entry control. Based on Piezo technology, these products offer an exceptional battery life of 500,000 operations from the 4x1.5v AA cells@2900mAh.
-New Piezo Technology
-Over 500,000 operations from 4xAA cells
-PVD, weather resistant, low maintenance finish
-Connections for remote release by reception desk button
-Connections for release by alarm system
-Code free entry mechanically by key or electronically from keypad
-Allows up to 90 user codes 4, 5 or 6 digits long
-Tamper alarm and low battery warning
|
|
CL4000 is a medium duty electronic keyless lock offering all the functions of the CL2000, but with the benefit of full size lever handles which allow it to be used as the primary lock on doors where a knob operated lock would not be suitable.
-New Piezo Technology
-Over 500,000 operations from 4xAA cells
-PVD, weather resistant, low maintenance finish
-Connections for remote release by reception desk button
-Connections for release by alarm system
-Code free entry mechanically by key or electronically from keypad
-Allows up to 90 user codes 4, 5 or 6 digits long
-Tamper alarm and low battery warning
|
|
ADVANCE by Onity is a revolutionary new locking solution that is destined to change the way you look at hotel security design and technology. ADVANCE combines the proven reliability of the world's most trusted name in electronic locking with a fresh new aesthetic that is designed to meet the needs of the demanding hospitality environment.
|
|
|
|
|
|
ADVANCE RFID Electronic Lock
RFID reader technology is the most recent option added to the ADVANCE line. Onity’s ADVANCE RFID locking solution is engineered utilizing the secure and reliable reader technology, which is MiFare® and NFC (Near Field Communication) compatible, and meets the most stringent standards in the industry, including ISO14443A and ISO14443B (part 4). It is also BHMA 156.25 and BHMA 156.13 certified.
The system employs multiple levels of encryption in order to maximize security. All Onity ADVANCE RFID cards are encrypted with the NXP Crypto-1 encoding algorithm, used in more than 1 billion smartcards throughout the world. For even more advanced security, Onity has taken the additional step of further encrypting the information. This encryption is unique to Onity, and provides an extra level of protection.
ADVANCE RFID offers a selection of aesthetic options, including finishes, handle designs, and cover plates that allow blending the locks into any décor.
Upgradeability
Onity’s ADVANCE RFID contact-less electronic locking solution is designed to make it quick and affordable to upgrade from traditional magstripe locking technology to RFID. The ADVANCE lock’s modular two-piece design allows current Onity ADVANCE customers to complete a technology upgrade with only a simple “plug & play” replacement of the card reader, which in most cases takes just a few minutes per door to install.
In addition to replacing the lock reader, a central office software upgrade is all that is needed to complete the ADVANCE RFID installation. The lock handle, hardware and other electronics need not be replaced.
|
|
Crafted for any property size, this Windows® based solution helps your staff perform at optimum efficiency. Its intuitive user-friendly design makes it easy to learn and use.
HT24: System with magstripe card lock
HT28: System with DUAL magstripe/Smart card lock
|
|
VingCard Classic hotel lock is the robust lock you have come to trust
VingCard's Classic guestroom locks have been carefully designed and engineered to our own exact standards, in order to provide the quality you need to secure your valuable property and guests. Operated with a highly reliable magnetic stripe- and/or a smartcard system, the VingCard Classic door lock offers a number of unique safety and operational features, yet they are exceptionally easy to operate and maintain. With over 15 years of proven performance in thousands of hotels throughout the world, VingCard's Classic hotel locks continue to set the standards in the industry.
Classic electronic lock for hotel is available with both a magnetic stripe card reader and a optional dual magnetic-/smart card reader, using either 2800 or VISION electronic locking system.
|
|
|
|
|
|
Your Signature… Unique and personal. An identifying characteristic that sets you apart from everyone else.
Signature by VingCard, A new electronic hotel lock that is unique and personal for your hotel design. An identifying characteristic that makes your electronic lock blend in with your hotel environment, regardless of style.
Hoteliers, architects, security experts and interior designers told us that design integrity is important. Therefore, electronic locks should blend in to the design of your hotel.
Guests told us that reliability and ease of use are important when entering their rooms. Therefore, Signature by VingCard is designed with human factors and ergonomics in mind.
Signature Trend by VingCard
‘Signature Trend’ by VingCard is especially suited for contemporary and modern hotel environments. It enhances the overall image of the corridor with the slim and discreet bezel which perfectly blends into the door, creating a pleasing and retrained image.
Signature Décor by VingCard
'Signature Décor’ by VingCard has been designed with the classic and decorative hotel styles in mind. With its elegant curved bezel, Décor provides an exclusive image with the ambience of a classic and decorative style, enriching the overall atmosphere.
|
|
|
Quantum™ MT : the modular feature of the sectional Quantum™ lock was created to address the need for both form and function. The sectional trim lock is a contemporary and modern two-piece modular design that offers flexibility in aesthetics and functionality.
|
|
QUANTUM ODYSSEY™ sleek design, surved edges and flawless finishes complement the changing architectural and design demands of the luxury hospitality market.
Kaba-Saflok also replaced the LED access indicator lights of its previous lock models with an illuminated keycard slot to reinforce its clean, sophisticated facade.
|
|
|
MT™ is a multi-technology locking system. The non-volatile FLASH circuitry stores up to 5,900 entries to provide detailed audit-trail information, such as date and time of the entry as well as the ID code of the employee or guest using the keycard. The MT™ lock is easy to use and works with the Windows-based System 6000™ and DeskLinc™ front desk systems. A mechanical key override (MKO®) feature is also available.
|
|
The New Codelocks narrow stile lock is a medium duty mechanical codelock suitable for use with aluminium doors. The lock is ideal for new or retrofit applications.
Designed to be retrofitted to Adams Rite or similar style mortice latch locks.
The new narrow stile mechanical Codelock provides access control in the following ways
-By Code via the keypad
-By key which can override the code and retract the latch
-The key can also be used to lock out code users
-Code free operation can be selected with the 0465 and 0475 models
Other features
-Non Handed - suitable for left or right hand hung doors, makes ordering/fitting very simple
-Full size lever handles standard, ball shape knobs available
-Easy installation
-PVD stainless steel finish
-Includes cams and fixing tabs
|
|
Particularly reliable and robust
Ideal for communal areas, or rooms used by the general public
Vandal-proof case
French Post Office approval
Numerous adaptations possible
Applications:
The Keylex 2000 is a mechanical, code-operated
access control unit designed for intensive use
in communal areas used by the general public:
dwellings (entrances, garage access, cellars,
shared-use rooms, etc.), industrial sites, hospital
and private clinics, public service buildings, railway
stations, airports, leisure centres and sports
grounds, supermarkets, etc.
Design features:
-Replaces the door hardware and lock
-The existing cylinder and key can be kept
-Free passage function as standard
-Easy code changing
-Satin nickel finish
-Reversible for right-hand/left-hand doors
|
|
The Codelock 500 series push button lock is a heavy duty mechanically coded lock with full size lever handles for use in high traffic situations. The lever handles allow it to be used as the primary lock on most doors, whilst the functions provide for control of the door in various ways.
-Heavy duty push button lock
-PVD, weather resistant, low maintenance finish
-Full size lever handles
-Outside lever has a slipping clutch to avoid damage to the mechanism if forced
-Easy code change as often as required
-Code free option available on both Mortice Lock and Mortice Latch functions
|
|
Easy to fit
Two versions available:
-tubular latch bolt
-surface deadbolt
Option: exit rod
Applications:
-The Jokey 500 is a mechanical, code-operated
lock or deadbolt designed to be used as an
additional device on low-frequency use doors:
cupboards, small storerooms, outbuildings,
garden sheds, etc.
Design features:
-Generally fitted to complement an existing lock
-Easy code changing
-Back-up cylinder as an option
-Metallic grey finish
-Reversible for right-hand/left-hand doors
|
|
Push button mechanical locks, ideal for restricting access for low usage doors i.e. stock cupboards, staff toilets, your office... the list goes on. Four standard functions to choose from to suit specific requirements.
-Fully mechanical
-Easy to fit, with all parts and fixings included
-5 functions in 2 PVD finishes
-Suitable for internal and external use
-Code can be changed quickly, as required
-Over 8,000 codes to choose from
|
|
Easy to fit
to all types of single-point locks
Ideal for narrow stiles
Handle or knob
Available in bolt version
Quick code setting
Applications:
-The Keylex Slim-line is a mechanical, code-operated
access control unit designed to be used singly or in a
group on doors to high-value rooms used frequently:
entrance doors to dwellings or businesses, IT rooms,
shop checkouts, laboratories, doctors%u2019 surgeries, etc
Design features:
-Replaces the existing door hardware for
spindle/latch offsets of 70, 72, 85, 90 and 92 mm
-The existing lock, cylinder and key can be kept
-Narrow-stile design for fitting to all types of door
(solid, narrow aluminium or PVC (42 mm min.) etc.).
-Easy code changing
-Free passage function (as an option)
-Metallic grey finish
-Reversible for right-hand/left-hand doors
|
|
Easy to fit to solid doors only
Ideal as an auxiliary device
Applications:
-The Jokey 1000 is a mechanical, code
operated access control unit designed to be
used as an additional device on mediumfrequency
use doors: bedrooms, individual offices, etc.
Design features:
-Replaces the existing door hardware
-The existing lock, cylinder and key can be kept
-Easy code changing
-Free passage function as standard
-Satin nickel finish
-Reversible for right-hand/left-hand doors
|
|
The Codelock 400 series is a medium duty mechanical combination lock with full size lever handles. The lever handles allow it to be used where the knob operated push button lock is unsuitable.
The functions available allow for control of the door in various ways for office, educational, local authority or other medium duty commercial and residential applications.
The Codelock 400 has the following available features:
-Medium duty Codelock
-PVD, weather resistant, low maintenance finish
-Full size lever handles
-Outside lever has a slipping clutch to avoid damage to the mechanism if forced
-Easy code change as often as required
-Code free option available on both Mortice Lock and Mortice Latch functions
|
|
|
|
|
|
Onity HT Prox
Featuring radio frequency technology, the Onity HT Prox lock eliminates the need to insert the card in the lock, making it much friendlier for the guest. It is ideal for hotels that wish to offer a “tech-touch" as well as Resorts for which the flexibility to choose “custom key shapes” is important, i.e. wristbands, tokens, stickers, etc.
With a speed of 210 ms (milliseconds), well below the 350ms intuitiveness limit, Onity’s ultra-fast reading ensures successful opening at the first attempt, avoiding guest frustration. This speed is provided ensuring a battery life of more than 2 years, using 4 standard AA batteries.
HT Prox works with ISO-standard non-proprietary cards, a platform with endless future projection as the technology is widely shared. In addition, the fact that HT Prox includes the word “OPEN” in Braille and a buzzer, turns it into the ideal electronic lock for disabled people.
5005 The quality and service you know, evolution in technology With more than 3.000.000 locks installed worldwide, over 20.000 properties have already experienced the Onity quality and service. Now enjoy the same high standards with the added advantages of the latest technology
|
|
Quantum™ RFID lock is designed to answer the need when design and beauty are as equally important as technology and functionality.
Using the latest Radio Frequency Technology, Quantum™ RFID and keycard communication is conducted via RF waves.
|
|
|
With the MT™ RFID lock, the MT lock is updated and enhanced with an RFID reader, which is compatible with MIFARE credentials. The MT RFID features a flush-mounted reader and is ideal for the retrofit market.
|
|
|
|
