Parking barrier TTSBPT4

boomthermo-lacquered steelaluminum

Presentation
The A3M TTSBPT4 parking barrier is a heavy‑duty motorized automatic barrier designed for intensive use. It features an oversized mechanism and an aluminum single‑boom for reliable control of vehicle access across adjustable widths from 2.5 to 4 m, suitable for public car parks, corporate parking areas, sports clubs and leisure facilities.

Application areas

• Entry/exit control for public and private parking lots
• Access control for construction sites and temporary facilities
• Light vehicle access — standard version
• Boom length adjustable/cuttable from 2.5 m to 4 m

Operation and compatibility
TTSBPT4 is an impulse‑operated automatic barrier with adjustable delay before automatic closing. It is compatible with most payment kiosks via a dry contact relay output (NO terminals) allowing automatic opening from external parking electronics. Badge readers can be integrated on a posts or control terminals.

Safety

• Photoelectric safety cell to prevent the boom from descending on vehicles or persons
• Rubber profile on the boom to minimize impact in case of contact
• Manual open/close mode and emergency release for operation during power loss or fault

Options and accessories

• Remote control (optional, up to 1000 remotes supported)
• Orange flashing beacon (optional)
• Integrated LED system in the boom (on request)
• Stainless steel (AISI 304) support post for badge readers — reader height 1.10–1.30 m; VL/PL version available with 220 cm height
• End‑fork for boom available as option

Installation and maintenance
Mount the barrier plate by anchoring into a concrete foundation to ensure fixation strength. The barrier housing is fabricated in painted steel (RAL 3002) with anti‑rust treatment. The mechanism includes adjustable limit stops to ensure horizontal and vertical alignment of the boom even on uneven ground.

Technical specifications

• Model: TTSBPT4
• Brand: A3M
• Passage width adjustable: 2.5 m to 4 m (boom cuttable)
• Boom: aluminum single‑tube (standard outdoor version)
• Operating temperature: -20 °C to +60 °C
• Housing: painted steel RAL 3002 with anti‑rust finish
• Safety: photoelectric cell
• Boom protection: rubber profile
• Control: dry contact relay input (NO terminals) compatible with payment kiosks
• Modes: impulse opening, adjustable delay, hold upright, close on second impulse
• Emergency release/manual opening in case of power failure or fault
• Stock: several versions available; custom adjustments possible
• Remote capacity: up to 1000 remotes
• Adjustable end stops for horizontal and vertical positions; rigid mechanism does not require support lyre (end fork optional)
