IP65 floodlight MINARET

LEDcommercialoutdoor

APPLICATION LED high-performance lights with Wide & Asymmetric Beam light distribution PRODUCT DESCRIPTION Luminaire made of aluminium, Aluminium and stainless steel. Clear plexiglass Silicon rubber gasket Mounting bracket made of aluminium with electrostatic powder coating. Lens angle 30°- 60° Colour standard MT-X6-23 optional RAL codes. LED power supply unit Input 100 – 305V AC 50 / 60 Hz Power factor > 90% full load 6kV surge protection DALI controllable (optional) 0-10V / 1-10V controllable (optional) Safety class I Protection class IP65 Impact strenght IK09 Operation temperature -25°C / +55°C Wind catching area: 0,23 m² Weight: 7 kg EULUMDAT files available Complies with European standards - Conformity mark. LAMPS Module connected wattage 50W Luminaire connected wattage 60W Ambient température ta max = 55 °C NW Module désignation 10S109344NC-40 Colour température 4000K Colour rendering index Ra>80 Module luminous flux 7516Im Luminaire luminous flux 7065Im Luminaire luminous efficiency 141 Im / W WW Module désignation 10S109344NC-40 Colour température 3000K Colour rendering index Ra>80 Module luminous flux 7000Im Luminaire luminous flux 6579Im Luminaire luminous efficiency 131 Im /W Standard colour température 4000K Also available with 3000K on request.
