Double-handle bathtub mixer tap ALR15

built-inwall-mountedmechanical

Description
Wall-mounted bath/shower mixer ALR15 with hand shower, double-control movement and Ø 80 mm spout, designed for architectural bathroom installations.

Features

• Type: wall-mounted bath/shower mixer with hand shower
• Movement: double-control
• Spout: Ø 80 mm
• Requires built-in body
• Accessory available: auxiliary bracket for plasterboard / fibrogesso
• Material: stainless steel (non-chromed, non-galvanic), eco-compatible and recyclable
• Standard finishes: Satin (S), Polished (L)
• Special finishes available: KD (Black Diamond), Z (Bronze), P (Copper), X (Light Gold)
• Hoses: silicone rubber in multiple colours (RAL codes listed)

Documents

• Dimensional drawing

Available finishes
S | Satin with polished detail

Special finishes

• KD | Black Diamond
• Z | Bronze
• P | Copper
• X | Light Gold

The special finishes are produced on request by depositing high-thickness mixtures of zirconium and graphite powders. These powders condense in vacuum/plasma chambers to create a surface layer that increases resistance to cleaning agents, saline air and abrasion. The Black Diamond version also limits limescale deposits due to its self-lubricating surface, improving cleanliness over time. All special finishes are ecological and biocompatible. Colour variations or tonal shifts are inherent to the production process and not defects.

Hoses
Silicone rubber hoses

• W | White — RAL 9016
• AB | Aviation blue — RAL 5014
• B | Cobalt blue — RAL 5013
• G | Anthracite grey — RAL 7043
• DB | Quartz grey — RAL 7006
• SG | Silk grey — RAL 7044
• BK | Black — RAL 9004
• A | Aqua green — RAL 6027
• PG | Petrol green — RAL 5020

Silicone rubber is lightweight and flexible, commonly used for hand-showers as an alternative to steel-braided hoses. It offers hygienic properties, chemical resistance and limescale resistance, and withstands thermal stress (from -55°C to +200°C), oxidation and tearing, making it suitable for indoor and outdoor installations. The silicone used is produced from paste processing and is available in a wide colour range.

Article code legend
Model | Article | Colour | Wood essence | Special finish | Finish
ZIQ | 02 | / | / | X | L
GIO | 25 | W | N | KD | S

S satin finish
L polished finish

Example 1
ZIQ 02 X L
Model: ZIQQ — Article: 02 — Special finish: X Light Gold — Finish: L polished

Example 2
GIO 25 W N KD S
Model: GIOTTO — Article: 25 — Hose colour: W White — Wood essence: N Noce Canaletto — Special finish: KD Black Diamond — Finish: S satin

Technical characteristics / specifications

• Type: wall-mounted bath/shower mixer with hand shower
• Movement: double-control
• Spout: Ø 80 mm
• Requires built-in body
• Accessory: auxiliary bracket for plasterboard / fibrogesso
• Material: stainless steel (non-chromed, non-galvanic), eco-compatible and recyclable
• Standard finishes: Satin (S), Polished (L)
• Special finishes: KD (Black Diamond), Z (Bronze), P (Copper), X (Light Gold)
• Hoses: silicone rubber in multiple RAL colours
