KEY FEATURES
- LED profile spot
- Light source: Tungsten or Daylight COB LED
- Powered directly through standard Power Dimming Units
- Soft profiling thanks to Fresnel and PC optics
- Smooth 16 bit dimmer
- Guaranteed flicker-free operation (DMX controlled PWM frequency)
- The fan setting allows three options: low, auto, DMX regulated
- Instant gobos from standard printers
SPECIFICATIONS
Fixed white CCT: 5.600 K
Four blade framing system, each shutter blade is adjustable for radial position and angle
Electronic 16 bit dimming with 2 selectable curves, simulating halogen or discharge lamp based fixtures
Synchronized, random or pulse electronic strobe
Flicker-free operation with LEDs frequency controlled via DMX from 640 to 1.500 Hz
Fan setting with 3 different options (low, auto or DMX regulated)
CE approved
IP rating: 20
LIGHT SOURCE
Daylight COB LED (CRI 80, TLCI 72 / CRI 90, TLCI 91). Average LED lifetime: a minimum of 80% of the initial luminous flux will be maintained after approx. 50.000 hours of usage (50.000 LM80).
PHYSICAL SIZE
Length: 362 mm (14.2 in) - with Profile Zoom 28°/40° optic: 601 mm (23.6 in)
Width: 212 mm (8.4 in)
Height: 189 mm (7.5 in) - with bracket: 372 mm (14.6 in)
Weight: 6 Kg (13.2 in) - with Profile Zoom 28°/40° optic: 8.3 Kg (18.3 lbs)
CONTROL PROTOCOL AND PROGRAMMING
Dimming controlled via standard external power dimming unit or with potentiometer knob
USITT DMX512A
DMX channels: 5
Setting, addressing, testing and measurements via LEDs display
RDM (Remote Device Management)
ELECTRICAL SPECIFICATIONS CONNECTIONS
AC power: 90-230 V, auto-sensing, 50/60 Hz
