KEY FEATURES
- LED profile spot IP 65
- RGBLA color mixing
- CCT proportional control from 2.700 to 6.500 K (CRI > 85)
- Dual gobo rotator included
- Profile zoom from 17° to 38° or from 10° to 25°
- Electronic 16 bit dimming with 3 selectable curves (Exponential, Logarithmic and Linear)
- Fan setting with 2 different options (auto, DMX)
- Guaranteed flicker-free
- Four blade framing system available as accessory
SPECIFICATIONS
Red, Green, Blue, Lime, Amber color mixing with hue and saturation control
CCT: all whites from 2.700 to 6.500 K
Dual gobo rotator included (standard gobo size B)
IP rating: 65 (weatherproof)
Profile zoom from 17° to 38° or from 10° to 25°
Electronic 16 bit dimming with 3 selectable curves (exponential, logarithmic, linear)
Pulse electronic strobe
Flicker-free operation with LEDs frequency controlled via DMX from 600 to 19.000 Hz
Fan setting with 2 different options (auto, DMX)
CE approved
LIGHT SOURCE
RGBLA LEDs module (CRI > 85). Average LED lifetime: a minimum of 80% of the initial luminous flux will be maintained after approx. 50.000 hours of usage (50.000 LM80).
PHYSICAL SIZE
Length: 687.8 mm (28.07 in) - 807.7 mm (31.8 in) with 10°-25° Optic
Width: 266 mm (10.47 in)
Height: 185 mm (7.28 in) - with bracket: 518.5 mm (20.41 in)
Weight: 14 Kg (30.8 lbs) - 15.5 Kg (34.2 lbs) with 10°-25° Optic
CONTROL PROTOCOL AND PROGRAMMING
USITT DMX512A
Setting, addressing, testing and measurements via LEDs display
DMX channels: 19 / 10 / 4 / Studio mode / RGB mode
RDM (Remote Device Management)
ELECTRICAL SPECIFICATIONS CONNECTIONS
AC power: 80-264 V, auto-sensing, 50/60 Hz
Internal cable without power plug
