Playground play tower ARGO

for public entitywith slidestainless steel

Overview
The Argo playground is a unique space-themed play tower equipped with 3 slides, 2 elevated platforms, and interactive panels that stimulate imagination. Its innovative, safe, and durable design makes it the best choice for outdoor playgrounds in schools, municipalities, hotels, and communities.

Product Details
The Argo outdoor playground is a multi-play set designed to offer fun, learning, and socialization for children of different ages. Its spaceship aesthetic with a dome and lookout invites children to imagine traveling through space while enjoying hours of entertainment.

This outdoor playground consists of:

• 1 easy-access staircase with handrails.
• 2 elevated platforms connecting a central tower with a space dome.
• 3 slides (one simple and one double) providing variety and excitement in every descent.
• Interactive play panels that stimulate imagination and enrich the play experience.

Thanks to its compact design, the Argo playground allows simultaneous participation of several children, fostering socialization, cooperation, and active play.

Made with vandal-resistant materials, weather-resistant and suitable for intensive use, the Argo Outdoor Playground is designed to last in perfect condition for years, maintaining safety and visual appeal intact.

An ideal solution for public parks, schools, hotels, campsites, and communities looking to create unique, safe, and imaginative play areas.

Certification and Approval
Playground approved for public and commercial use, designed for children aged 1 to 6 with maximum European safety:

• Approved and certified by TÜV.
• Complies with EN 1176-1:2017/A1:2023 and EN 1176-3:2017 standards, specific for outdoor playgrounds.
• Staircases with handrails and safe platforms.
• Smooth surfaces, without sharp edges or roughness.
• Vandal-resistant materials ensuring resistance to intensive use and environmental factors.

Main Features

• Maximum Durability and Low Maintenance: Thick galvanized steel structure with powder coating for excellent rust and weather resistance. Panels and slides are made of UV-resistant polyethylene, ensuring vibrant colors and low maintenance.
• Structural and Vandal-Proof Safety: Use of special screws, caps, and vandal-proof clamps to ensure integrity and prevent tampering.
• Stimulating and Accessible Design: Space-themed design with protective roofs and elements that stimulate creativity. Includes wide staircases with handrails for safe access and efficient flow of children.
• Promotes Comprehensive Development: Designed to promote physical activity (motor coordination, balance, and strength) and cognitive and social development through play elements that boost imagination and simultaneous use of facilities.

Technical and Safety Specifications

• Dimensions (mm): 4110 × 2427 × 3462
• Maximum fall height (mm): 800
• Safety area (mm): 8110 × 6427
• Standards: TÜV certified. Complies with EN 1176-1:2017/A1:2023 and EN 1176-3:2017.
• Recommended age of use: 1 to 6 years.
• Recommended use: Public parks, schools, kindergartens, hotels, campsites, and residential areas.

Materials and Manufacturing Processes

• Structure: Main posts in Ø89 mm galvanized steel tubes, 2.5 mm thick, treated and oven-painted with polyester powder for outdoor use (UV, corrosion, and temperature resistant). Secondary parts in Ø60, Ø48, Ø38, Ø32, and Ø28 mm galvanized steel, also 2.5 mm thick.
• Platforms and Stairs: 2.5 mm thick galvanized steel plate, perforated with Ø8 mm holes for drainage and anti-slip safety. Surface oven-painted with polyester powder.
• Panels, Roof, and Slides: Made of rotomolded polyethylene dyed in mass. Wall thickness over 6 mm, UV resistance (grade 8), and anti-static properties.
• Sliding Ramp: High-Density Polyethylene (HDPE), ensuring maximum resistance and durability.
• Screws and Accessories: Galvanized or AISI-304 stainless steel screws. Vandal-proof caps and clamps. High-strength aluminum alloy fixings with rounded corners.

Installation

• Installation – Type I: For hard surfaces (concrete), fixation is done with bolts or expansion screws on concrete pads or slabs. Requires safety surface (rubber or other cushioning material).
• Installation – Type II: For soft ground (soil or sand), posts must be buried in the ground and anchored with concrete.

Features / Technical Specifications

• Ref. TTDU-003
• Dimensions: 4110 × 2427 × 3462 mm
• Maximum fall height: 800 mm
• Safety area: 8110 × 6427 mm
• Recommended age: 1 to 6 years
• TÜV certified
• Complies with EN 1176-1:2017/A1:2023 and EN 1176-3:2017
• Galvanized steel and UV-resistant polyethylene structure
• Vandal-resistant materials
• Use: public parks, schools, hotels, campsites, residential areas
