4-sided fireplace insert CASSETTE 400 600

electricmetalcontemporary

Product overview
The Cassette 400/600 inset electric fire CAS400NH by dimplex delivers a four-sided free-floating flame and smoke effect using Optimyst LED technology. Compact and modular, it requires only a 230 V supply and a filled water reservoir to produce realistic flame and smoke effects for interior design, hospitality and residential installations.

Key features

• Optimyst flame and smoke effect with all-round (4-side) view
• LED illumination for lower power consumption and extended lamp life
• Removable easy-fill water tank (0.75 L) with approximately 8–12 hours runtime
• Crackling logs sound effect with adjustable volume
• Manual controls and remote included; hotel mode available

Technical specifications

• Model: CAS400NH
• Model number: 210791
• Brand: dimplex
• GTIN/UPC: 05011139210791
• Power consumption (flame effect): 125 W
• Lamp type: LED
• Dimensions (HxWxD): 176 x 407 x 220 mm
• Weight: 4.5 kg
• Water tank capacity: 0.75 L
• Water tank runtime: 8–12 hours
• View type: All-round view
• Fuel bed: Metal plate
• Controls: Manual and remote
• Hotel mode: Yes
• Warranty: 2 years

Applications and installation

• Designed for inset installation in tables, within gas or wood fireplaces, or aligned side-by-side for a linear fire effect
• Requires 230 V electrical supply; bottle-fed water refill system
• Suitable for residential interiors, hotel lobbies, showrooms and hospitality projects

Maintenance and use

• Removable, easy-fill tank simplifies maintenance and refilling
• LED technology reduces lamp replacements and maintenance frequency
• Refer to the installation manual for mounting, electrical connection and hotel mode configuration
