Cellular polycarbonate panel arcoPlus® 625buildingwith UV protectiontranslucent
Add to favorites
Compare this product
Characteristics
- Type
- cellular
- Applications
- building
- Other characteristics
- with UV protection, translucent, insulated, interlocking
Description
arcoPlus®625 is a modular system of coextruded 5 walls polycarbonate panels with a thickness of 20mm, aluminium profiles, accessories and opening windows, designed for simple and versatile use. arcoPlus®625 is not suitable for roofing applications.
Production standard
Thickness - 20mm
Structure - 5 walls
Effective modular width - 667mm
Panel length - No limits
Available colors - Standard + Caleido + RTG
Features
Thermal insulation - 1,7 W/m²K
Acoustic insulation - 16 dB
Linear thermal expansion - 0,065mm/m°C
Temperature range - -40°C +120 °C
U.V. rays protection - Coestrusione
Fire reaction EN 13501-1 - EuroClass B-s1,d0
Advantages
Easy and low-cost installation
Light transmission
Resistance to UV rays and to hail
Thermal insulation
