LED track light JILLY

squarepolymeraluminum

Jilly is a family of track‑mounted downlights engineered for efficient, standards‑compliant lighting of office workplaces. Its flat housing and anti‑dazzle louvre deliver high visual comfort while enabling flexible layout via track mounting.

Special features

• Anti‑dazzle louvre: limits direct view into the light source (emission angle 90°) for low glare; standard louvre finishes in black or silver, additional finishes on request.
• Designed for office workstations: good glare control and high visual comfort; apply UGR guidance according to luminaire arrangement rather than blanket values.
• Low construction height: flat housing suitable for rooms with limited ceiling height and discreet integration.

Product description

• Track‑mounted downlight combining a highly efficient ERCO lens system with an anti‑dazzle louvre to provide visual comfort and high luminous efficacy. Wattage and distribution options support wide luminaire spacing for economical, standards‑compliant office lighting. Track mounting allows flexible alignment to workstation layouts.

Individualisation / variants

• Anti‑glare louvre finishes: gold matt, silver matt, champagne matt, copper matt and other colours on request.
• Housing colours: standard white (RAL9002), black or silver; extensive custom colour options (ERCO Individual) on request.

Structure / main components

• ERCO lens system: optical polymer; available light distributions: Extra wide flood, Oval wide flood.
• ERCO LED module: mid‑power LEDs; colour temperatures: 2700K, 3000K, 3500K, 4000K.
• Louvre: polymer (black lacquered) or aluminium vapourised (silver, mirror finish); anti‑dazzle design to restrict direct sight of the source.
• Housing: coated polymer; standard finishes white (RAL9002), black or silver; luminaire rotatable 360° on adapter.
• Control gear options: switchable; phase dimmable + On‑board Dim (rotary control and compatible with trailing‑edge dimmers); DALI dimmable; Casambi Bluetooth.
• Adapters: ERCO 3‑circuit adapter or ERCO DALI adapter for track mounting.

Characteristics / technical specifications

• Indicative light source power: 14.1 W – 14.2 W (downlight variants).
• Luminous flux: approx. 2610 lm – 3080 lm for indicated downlight variants.
• Correlated Colour Temperatures (CCT): 2700K, 3000K, 3500K, 4000K.
• Lens material: optical polymer.
• Available light distributions: Extra wide flood; Oval wide flood.
• Louvre materials/finishes: polymer (black lacquered) or aluminium vapourised (silver, mirror finish); additional coated colours on request.
• Housing colours: White (RAL9002), black, silver; extensive custom colour options on request.
• Mounting: Track (ERCO 3‑circuit or DALI adapter); luminaire rotatable 360° on adapter.
• Control: Switchable; Phase dimmable + On‑board Dim; DALI dimmable; Casambi Bluetooth.
• Typical applications: ambient and workstation lighting in offices; suitable for low room heights and flexible layouts due to track mounting.
• Family performance note: designed for high visual comfort and luminous efficacy enabling wide luminaire spacing for economical, standards‑compliant office lighting.
