LED track light JILLY LINEAR

rectangularmetalfor office

Jilly linear is a track-mounted downlight from ERCO designed to provide efficient, standard‑compliant lighting for modern office and co-working spaces with ceiling heights up to 5 m. The luminaire features a flat housing and a pronounced anti-glare louvre to combine high luminous efficacy with excellent visual comfort and allows flexible repositioning along the track.

Key product highlights:

• Suitable for office workstations: designed for good glare control and high visual comfort (UGR considerations for room-specific arrangements).
• Office lighting for high rooms: high-output light suited for room heights up to 5 m.
• Louvres for efficient visual comfort: anti-glare louvre (emission angle 90°) in black or silver to integrate with ceiling materials and colours.
• Low construction height: flat housing for an elegant appearance with focus on the light.

Individualisation / variants:

• Anti‑glare louvre finishes: gold matt, silver matt, champagne matt, copper matt or other colours on request.
• Housing colours: choice from 10,000 further colours (powder-coated aluminium profile/polymer).

Product features in detail:

• ERCO lens system
  • Made of optical polymer.
  • Available light distributions: Extra wide flood or Oval wide flood.
• ERCO LED-module
  • Mid-power LEDs available in warm white (2700K, 3000K) and neutral white (3500K, 4000K).
• Louvre
  • Material/finishes: polymer black lacquered or aluminium vapourised (silver, mirror‑finish).
• Housing
  • Standard colours: White (RAL9002), black or silver.
  • Construction: aluminium profile / polymer, powder-coated; flat, low-height design.
• Control gear
  • Options: switchable, DALI dimmable or Casambi Bluetooth.
• Track adapters
  • ERCO 3‑circuit adapter or ERCO DALI adapter and mechanical adapter for track mounting.

Technical specifications:

• Mounting: Track-mounted, slidable in the track for flexible positioning.
• Intended application: Standard-compliant office workplace lighting, suitable for high co-working spaces up to 5 m.
• Light source rating (examples): 34.7 W modules with luminous flux ranges shown for wide distributions (approx. 6494 lm – 7661 lm depending on configuration).
• Light distributions: Extra wide flood; Oval wide flood (orientation-dependent for oval distribution).
• Available LED colour temperatures: 2700K, 3000K, 3500K, 4000K.
• Louvre emission angle: approx. 90° (anti-glare).
• Housing finishes: White (RAL9002), black, silver; many custom colours available.
• Control and dimming: Switchable; DALI dimmable; Casambi Bluetooth option.
• Materials: Aluminium profile / polymer housing; optical polymer lenses.
