CAD software TACHYCAD-BUILDING
drawingmonitoringcalculation

CAD software
CAD software
CAD software
Add to favorites
Compare this product


Characteristics

Type
CAD, drawing, monitoring, calculation, measurement
Applications
Autocad
Other characteristics
3D

Description

Leave the site with a finished plan Spot and rectify errors such as missing and inconsistent readings immediately Rework in the office is minimized The AutoCAD application TachyCAD is a solution for CAD-based inventory data collection. Measurements from common survey instruments are deployed immediately as CAD geometry. Depending on requirements, floor plans, sections, elevations or 3D objects are created locally as an AutoCAD drawing. The total station is your AutoCAD cursor TachyCAD enables transmission of measurement data from a total station to a notebook. At measurement initiation, the data is automatically transferred to the notebook. TachyCAD calculates and plots the 3D coordinates of the point. The survey data is made available for AutoCAD drawing and design processes in the same way as pointing with a mouse or by manual data entry. Measurement by Bluetooth-enabled hand lasers or total stations can be passed wirelessly to AutoCAD for immediate use. Optimized workflow in detail An extensive range of commands specifically developed for building survey are added to AutoCAD functionality. The basic principle of all commands is to achieve, with as few inputs and measurements as possible, the final presentation drawing. Area Calculation in Parallel to the CAD plan Space/area reports can be created quickly and easily in one convenient and customizable tree structure, the areas can be provided with additional information such as volume, asset locations and space usage. Room footprints and visualizations (e.g. different NRV depending on type of usage) can be produced on demand. Export of the FM attribute database is possible as well.

VIDEO
