Contemporary wall light RESIDENZA GEN2
outdoorpolycarbonatecast aluminum

Contemporary wall light - RESIDENZA GEN2 - Hess GmbH Licht + Form - outdoor / polycarbonate / cast aluminum
Contemporary wall light - RESIDENZA GEN2 - Hess GmbH Licht + Form - outdoor / polycarbonate / cast aluminum
Contemporary wall light - RESIDENZA GEN2 - Hess GmbH Licht + Form - outdoor / polycarbonate / cast aluminum - image - 2
Contemporary wall light - RESIDENZA GEN2 - Hess GmbH Licht + Form - outdoor / polycarbonate / cast aluminum - image - 3
Contemporary wall light - RESIDENZA GEN2 - Hess GmbH Licht + Form - outdoor / polycarbonate / cast aluminum - image - 4
Add to favorites
Compare this product

Characteristics

Style
contemporary
Interior/exterior use
outdoor
Material
glass, aluminum, cast aluminum, polycarbonate
Diffuser shape
cylindrical
Type of support
fixed
Applications
for public space
Light source
LED
Number of lights
single
Protection class
IP65
Color
black, anthracite
Other characteristics
IK08
Power

Max.: 34 W

Min.: 11 W

Luminous flux

Max.: 4,905 lm

Min.: 1,052 lm

Color temperature

Max.: 4,000 K

Min.: 1,700 K

Description

General
The RESIDENZA from Hess. A luminaire that is created like no other for holistic design concepts in urban space. Whether as an illuminating column, pole top mounted, wall mounted or catenary suspended luminaire – with the RESIDENZA from Hess, you always make the right choice: a diverse and therefore versatile lighting option.

Related Products
  • RESIDENZA Gen2 — Wall mounted luminaires (selected series)
  • RESIDENZA C Gen2 — Illuminating columns
  • RESIDENZA — Catenary suspended luminaires
  • RESIDENZA Gen2 — Pole mounted luminaires

Technical details
Protective cover made of PC glass. Luminaire rests on four aluminium rods. Cylindrical luminaire body made of cast aluminium, universal holder for poles with spigot 60.3 - 82.5 mm. Luminaire enclosure made of PC, clear. Diameter 200 mm. Light colour options: 1700K / 1900K / 2000K / 2200K / 2700K / 3000K / 4000K. Protection rating I or II.

Finishes & variants
RESIDENZA: Luminaire colour: DB 703 or all RAL (classic single shades), Hess-DB and Hess-Glimmer-colours. RAL pearl-mica-metallic-shades on request.

RESIDENZA ZERO: ULOR of 0%, complies with the Dark Sky Standard. Rods and internal parts uniformly painted, dark anthracite textured (similar to DB 703/Gris 2900 sablé).

Rated luminous flux
RESIDENZA Gen2 | 1052 - 4905 lm
RESIDENZA Gen2 ZERO | 1015 - 4734 lm

Other technical indicators
LED Lifetime: L90 B10 / 100.000h - TA <= 25° C
Ingress protection: IP65
IK-Value (PC): IK08

Technical features / specifications
  • Protective cover: PC glass
  • Mounting: Luminaire rests on four aluminium rods; universal holder for poles with spigot 60.3 - 82.5 mm
  • Body: Cylindrical luminaire body made of cast aluminium
  • Enclosure: Clear PC
  • Diameter: 200 mm
  • Light colour options: 1700K, 1900K, 2000K, 2200K, 2700K, 3000K, 4000K
  • Protection rating: Class I or II
  • LED lifetime: L90 B10 / 100,000 h (TA ≤ 25 °C)
  • Rated luminous flux (typical ranges): RESIDENZA Gen2 1052–4905 lm; RESIDENZA Gen2 ZERO 1015–4734 lm
  • Ingress protection: IP65
  • Impact resistance (PC): IK08
  • Colours & finishes: DB 703 or all RAL (classic single shades), Hess-DB and Hess-Glimmer colours; RAL pearl-mica-metallic on request
  • RESIDENZA ZERO specifics: ULOR 0% (complies with Dark Sky Standard); rods and internal parts uniformly painted dark anthracite textured

Catalogs

No catalogs are available for this product.

See all of Hess GmbH Licht + Form‘s catalogs
