Urban lamp post DALVIK

contemporarycast aluminumaluminum

Overview
The DALVIK is a compact pole-mounted luminaire with an extremely flat rectangular head, available in two variants: DALVIK S and DALVIK R. Designed for urban lighting concepts, it can be configured to meet project-specific technical requirements for uniform and individual lighting solutions.

Design & Variants
The luminaire features a seamless design bracket in brushed stainless steel and a timeless, adaptable aesthetic suitable for holistic urban design approaches. It can be fitted and equipped according to project needs.

Variants

• DALVIK R: Rectangular luminaire body made of cast aluminium with an attached circumferential stainless steel frame.
• DALVIK S: Rectangular luminaire body made of cast aluminium with two circumferential joints.

Mounting & Construction
Luminaire enclosure made of single-pane safety glass. Depending on the model, modular aluminium pole adapters are available for third-party poles (spigot 76.1 mm and 60.3 mm) and for Hess quality poles (spigot 82.5 mm and 88.9 mm).

Light & Protection
Available light colours: 1800K, 2700K, 3000K, 4000K. Electrical protection class: I or II.

Technical details (summary)
LED lifetime: L90 B10 / 100,000 h (Ta ≤ 25 °C). Ingress protection: IP66. Impact resistance: IK08.

Features / Technical specifications

• Luminaire type: Pole-mounted luminaire with extremely flat rectangular head
• Variants: DALVIK R and DALVIK S
• Enclosure: Single-pane safety glass
• Body material: Cast aluminium (DALVIK R and S)
• Frame (DALVIK R): Circumferential stainless steel frame
• Bracket: Seamless design bracket in brushed stainless steel
• Modular pole adapters: Aluminium adapters for spigot sizes 76.1 mm and 60.3 mm (third-party poles) and 82.5 mm and 88.9 mm (Hess quality poles)
• Light colours: 1800K, 2700K, 3000K, 4000K
• Protection class: I or II
• LED lifetime: L90 B10 / 100,000 h (Ta ≤ 25 °C)
• Ingress protection: IP66
• Impact resistance: IK08
