Urban lamp post RESIDENZA GEN2

contemporarypolycarbonatealuminum

General
The RESIDENZA from Hess is a cylindrical outdoor luminaire designed for integrated urban and architectural lighting concepts. Suitable as a column-mounted luminaire, pole-top, wall-mounted or catenary-suspended unit, it offers multiple installation variants to suit different urban contexts.

Technical details
Protective cover made of PC (polycarbonate). The light source assembly is supported on four aluminium rods. Cylindrical luminaire body made of die-cast aluminium. Universal pole holder for spigot Ø 60.3 - 82.5 mm. Luminaire enclosure: clear PC. Diameter: 200 mm. Electrical protection class: I or II.

RESIDENZA:
Luminaire colour options: DB 703 or any RAL (classic single shades), Hess-DB and Hess-Glimmer colours. RAL pearl-mica-metallic shades available on request.

RESIDENZA ZERO:
ULOR 0% (complies with Dark Sky Standard). Rods and internal parts finished uniformly in dark anthracite textured coating (similar to DB 703/Gris 2900 sablé).

Light colours

• 1700K
• 1900K
• 2200K
• 2700K
• 3000K
• 4000K

Rated luminous flux [lm]
RESIDENZA Gen2: 1052 - 4905 lm
RESIDENZA Gen2 ZERO: 1015 - 4734 lm

Ingress protection / Impact resistance

• Ingress protection: IP65
• IK rating (PC): IK08

Dimensions
Diameter: 200 mm

Characteristics / technical specifications

• Protective cover: PC (polycarbonate) transparent
• Luminaire body: die-cast aluminium (cylindrical)
• Support rods: aluminium (luminaire rests on four aluminium rods)
• Universal pole holder: spigot Ø 60.3 - 82.5 mm
• Luminaire enclosure: clear PC
• Diameter: 200 mm
• Light colour options: 1700K, 1900K, 2200K, 2700K, 3000K, 4000K
• LED lifetime: L90 B10 / 100,000 h (TA ≤ 25°C)
• Rated luminous flux: RESIDENZA Gen2 1052 - 4905 lm; RESIDENZA Gen2 ZERO 1015 - 4734 lm
• Ingress protection: IP65
• IK rating: IK08 (PC)
• Protection class: I or II
• Colour options: DB 703, any RAL (classic single shades), Hess-DB, Hess-Glimmer; RAL pearl‑mica‑metallic on request
• RESIDENZA ZERO: ULOR 0% (Dark Sky Standard compliant); rods and internal parts in dark anthracite textured finish
