The most popular line of fireplaces on offer.
Many options for personalizing the appearance: door handle, masking frames, black concrete.
Efficient system of maintaining clean glass.
FEATURES
Energy class - A
Ecodesign - +
BlmSchV II - +
Nominal power (kW) - 9
Heating load range (kW) - 4,5-12
Thermal efficiency (%) - 78,0
Dust emission [g/m³] - 0,036
Possibility to install the fireplace inserts with warm accumulative casing - YES
CO emission by13% O2 (g/m³) - 0,818
Weight (kg) - 112
Flue diameter (mm) - 180
Air intake diameter (mm) - 125
Glass dimensions (mm) - 545 x 390 x 325
Min. active field of outlet vents (cm²) - 630-720
Min. active field of inlet vents (cm²) - 360-590
Fuel Type - seasoned wood of deciduous trees (beech, birch, hornbeam) with humidity of 12-20%
DESCRIPTION
Schemat obiegu powietrza kominka 9.S.H
QUALITY:
Fireplace inserts are made of high-quality P265GH boiler steel, which is resistant to continuous operation at higher temperature.
Reinforced door profile is used.
REPEATABILITY:
Production process use modern machinery park: welding robots, press brakes, laser cutters.
ECOLOGY:
Comply with strict emission standards and the ECODESIGN, thanks to the use of an after-burning system and high efficiency.
In accordance with the requirements of the Ecodesign Directive in the EU Member States: "This product can not be used as the primary source of heating".
SECURITY:
An innovative ventilated handle protects against scalding.
Suitable for homes with recuperation.
EASY-TO-USE:
The built-in intake with the throttle enables smooth integrated regulation of the amount of air supplied.
