The most popular line of fireplaces on offer.
Many options for personalizing the appearance: door handle, masking frames, black concrete.
Efficient system of maintaining clean glass.
FEATURES
Energy class - A+
Ecodesign - +
BlmSchV II - +
15a B-VG - +
Nominal power (kW) - 19
Heating load range (kW) - 9,5-24
Thermal efficiency (%) - 81
Dust emission [g/m³] - 0,029
Possibility to install the fireplace inserts with warm accumulative casing - NO
CO emission by13% O2 (g/m³) - 1,2
Material - boiler of steel P265GH grade in accordance with EN 10088-2
Weight (kg) - 206
Flue diameter (mm) - 220
Air intake diameter (mm) - 150
Glass dimensions (mm) - 900 x 410 x 375
Min. active field of outlet vents (cm²) - 1330-1520
Min. active field of inlet vents (cm²) - 760-1240
Fuel Type - seasoned wood of deciduous trees (beech, birch, hornbeam) with humidity of 12-20%
DESCRIPTION
Schemat obiegu powietrza kominka 9.S.H
QUALITY:
Fireplace inserts are made of high-quality P265GH boiler steel, which is resistant to continuous operation at higher temperature.
Reinforced door profile is used.
REPEATABILITY:
Production process use modern machinery park: welding robots, press brakes, laser cutters.
ECOLOGY:
Comply with strict emission standards and the ECODESIGN, thanks to the use of an after-burning system and high efficiency.
In accordance with the requirements of the Ecodesign Directive in the EU Member States: "This product can not be used as the primary source of heating".
SECURITY:
An innovative ventilated handle protects against scalding.
Suitable for homes with recuperation.
EASY-TO-USE:
The built-in intake with the throttle enables smooth integrated regulation of the amount of air supplied.
