CAD software SMARTPLANT® SPOOLGEN®

architecturefor hydraulic and thermal installations3D

SmartPlant Spoolgen is a proven, industrial-strength application that enables the creation of piping isometric drawings for fabrication and erection from the design created during the detail engineering phase of projects. You can add additional information – such as the location of field welds – and create new drawings and reports from the same source as the original drawings. The technology is based on ISOGEN, the industry-standard software for automated piping isometric generation, and has been deployed successfully on all sizes of plant engineering projects in every region of the world. SmartPlant Spoolgen is fast and accurate because it eliminates the need to redraw isometrics and manually re-create material take off reports. SmartPlant Spoolgen can work with data from almost any plant design system – Intergraph® SmartPlant 3D, PDS®, and CADWorx®; AVEVA PDMS; and Bentley AutoPLANT and PlantSpace are all supported. SmartPlant Spoolgen boosts productivity because no CAD skills are needed, yet it uses the ISOGEN engine to create industry-standard, high-quality pipe spool drawings in many different formats – automatically and without drafting. Changes to the source data are strictly controlled to maintain design integrity, helping to eliminate transcription errors and ensuring that the design intent is faithfully preserved throughout the fabrication and erection phases.
