Compact crane 25 L

boomfixedself-erecting

Description
Quick-erecting cranes of the L series can be made ready for operation quickly. Their compact design makes them suitable for sites with limited space.

Key product data

• Standard: EN 14439
• Max. hook height: 19.10 m
• Max. lifting capacity: 2,500 kg
• Max. radius: 25.00 m
• Lifting capacity at max. radius: 950 kg

Technical data (table)
Lifting capacity at max. radius: 950 kg
Max. radius: 25.00 m
Standard: EN 14439
Max. lifting capacity: 2,500 kg
Max. hook height: 19.10 m
Luffed jib position: 10 / 20 °
Jib position to avoid obstacles: 160 °
Slewing radius: 1.95 m
Hoist gear: 8 kW FU
Slewing gear: 3.0 kW FU
Trolley travel gear: 2.0 kW FU

Characteristics / technical specifications

• Product type: Quick-erecting crane (L series)
• Model: 25 L
• Max. radius: 25.00 m
• Max. hook height: 19.10 m
• Max. lifting capacity: 2,500 kg
• Lifting capacity at max. radius: 950 kg
• Luffed jib position: 10 / 20 °
• Jib position to avoid obstacles: 160 °
• Slewing radius: 1.95 m
• Hoist gear: 8 kW (FU)
• Slewing gear: 3.0 kW (FU)
• Trolley travel gear: 2.0 kW (FU)
