Light switch PP-T01-A14B

touchelectronicrecessed

Description
Ready-to-fit one-way touch switch supplied complete (touch mechanism, metal frame, gloss white tempered glass faceplate). Designed for fast replacement or new installations, the switch operates without a neutral wire at the switch (neutral only at the luminaire) and is compatible with common wiring systems. The touch control provides smooth, intuitive operation while discreet LED backlighting ensures location in low light. The colour is applied behind the tempered glass for long-lasting resistance to scratches and discolouration.

Product highlights

• Complete ready-to-install unit
• One-way 1-circuit touch mechanism
• Tempered glass faceplate, white gloss
• Metal mounting frame included
• Discrete LED backlight for night location
• Works without neutral at the switch (neutral at light fitting)
• Quick installation on standard wiring and back boxes ≥ 40 mm
• Compatible with LED and halogen loads (min. 5 W)

Pack contents

• 1 x touch switch - one-way 1 button (ref. T01)
• 1 x glass faceplate - 1 button, white, gloss (ref. A-C1-11B)

Installation & compatibility

• Fits round or square back boxes ≥ 40 mm
• Mounting: horizontal or vertical
• For standard electrical installations
• No neutral required at switch location (neutral at luminaire)
• Compatible light sources: LED and halogen

What's in the box

• 1 touch switch mechanism - 1-button one-way
• 1 glass faceplate - 1 button, white, gloss
• 1 metal mounting bracket
• 1 installation guide

Caractéristiques / spécifications techniques

• Manufacturer: Livolo
• Reference: PP-T01-A14B
• Type: Touch faceplate switch
• Number of circuits: 1 lighting circuit
• Minimum load: 5 W
• Maximum power: 2000 W
• Material: Tempered glass (faceplate), metal frame
• Certification: CE & RoHS
• Function: One-way ready-to-fit switch
• Number of buttons: 1
• Categories: Ready-to-fit products, Switch
• Weight: 0.170 kg
