Light switch PP-T01S-A14B

touchrecessedmetal

Description Choose a ready-to-fit solution with this two-way touch switch supplied with its mechanism, metal frame and gloss white tempered glass faceplate. Designed to control a lighting circuit from two switching points, it is suitable for hallways, staircases, bedrooms and large rooms. The touch control provides smooth, intuitive operation while a discreet LED backlight makes the switch easy to locate in the dark. Compatible with standard installations, it does not require a neutral wire at the switch, simplifying installation in both renovation and new build. The tempered glass faceplate resists scratches and impacts; the colour is applied behind the glass to preserve its shine over time.

Product highlights

• Ready-to-install product
• Supplied complete (mechanism, frame, faceplate)
• Control of a light from two points (two-way)
• Precise, intuitive touch control
• Tempered glass faceplate
• Metal support included
• Discreet LED backlighting
• Compatible with LED and halogen lighting
• Quick installation on existing wiring
• Modern, elegant premium design

Pack contents

• 1 x touch switch - two-way, 1 button (ref. T01S)
• 1 x glass faceplate - 1 button, white, gloss (ref. A-C1-11B)

Installation & compatibility

• Compatible with round or square back boxes ≥ 40 mm
• Horizontal or vertical mounting
• For use on a standard electrical installation
• Neutral wire not required at the switch (only at the light fitting)
• Compatible light sources (LED and halogen lighting)

What's in the box

• 1 two-way 1-button touch switch mechanism
• 1 glass faceplate - 1 button, white, gloss
• 1 metal mounting bracket
• 1 installation guide

Technical specifications

• Manufacturer: Livolo
• Reference: PP-T01S-A14B
• Model: T01S
• Type: Touch faceplate
• Function: Ready-to-fit two-way switch
• Number of circuits: 1 lighting circuit
• Number of buttons: 1
• Minimum load: 5 W
• Maximum power: 2000 W
• Material: Tempered glass
• Certification: CE & RoHS
• Categories: Ready-to-fit products, Switch
• Net weight: 0.170 kg
• Pack supplied: touch mechanism, metal frame, gloss white tempered glass faceplate
