Light switch PP-T01S-A12B

touchelectronicrecessed

Short description
Ready-to-fit two-way touch switch supplied with mechanism, metal mounting bracket and gloss white tempered glass faceplate. Controls one lighting circuit from two locations; ideal for corridors, staircases and bedrooms. Smooth touch control and discreet LED backlighting for locating the switch in low light.

Overview
Modernise electrical installations with this ready-to-install two-way touch switch. Supplied complete for quick retrofit or new build installation. The switch operates without a neutral at the switch (neutral at the light fitting only), simplifying wiring in renovation projects. The tempered glass faceplate is scratch- and impact-resistant; the colour is applied behind the glass to preserve finish over time.

Product highlights

• Ready-to-install solution supplied complete
• Two-way function for control from two points
• Precise, intuitive touch control
• Tempered glass faceplate, gloss white
• Metal support bracket included
• Discrete LED backlighting for night visibility
• Compatible with LED and halogen light sources
• Quick installation on existing wiring

Pack contents

• 1 x touch switch mechanism - two-way, 1 button (ref. PP-T01S-A12B)
• 1 x glass faceplate - 1 button, white, gloss (ref. A-C1-11B)

Installation & compatibility

• Compatible with round or square back boxes ≥ 40 mm
• Horizontal or vertical mounting
• For standard electrical installations
• Neutral wire not required at the switch (neutral at the light fitting)
• Compatible with LED and halogen lighting

What's in the box

• 1 two-way 1-button touch switch mechanism
• 1 glass faceplate - 1 button, white, gloss
• 1 metal mounting bracket
• 1 installation guide

Technical specifications

• Manufacturer: Livolo
• Reference: PP-T01S-A12B
• Type: Touch switch mechanism with glass faceplate
• Number of circuits: 1 lighting circuit
• Minimum load: 5 W
• Maximum power: 2000 W
• Certification: CE & RoHS
• Material: Tempered glass
• Number of buttons: 1
