Light switch PP-T01S-A13B

touchrecessedmetal

Short description
Choose a ready-to-fit solution with this two-way touch switch supplied with its mechanism, its metal frame and its gloss white tempered glass faceplate.

Overview
Modernise your electrical installation with this ready-to-fit two-way touch switch, supplied with everything needed to install it: touch mechanism, metal frame and gloss white tempered glass faceplate.
Designed to control a lighting circuit from two switching points, it is an ideal solution for hallways, staircases, bedrooms or large rooms.
Its touch control offers smooth, intuitive use while its discreet LED backlighting makes the switch easy to locate in the dark.
Compatible with standard electrical installations, it works without a neutral wire at the switch, which makes it easy to install in both renovation and new build.
Made from tempered glass, the faceplate resists scratches, impacts and wear; the colour is applied behind the glass to retain its gloss over time.

Product highlights

• Ready-to-install product
• Supplied complete (mechanism, frame, faceplate)
• Control of a light from two points (two-way function)
• Precise, intuitive touch control with LED backlight
• Tempered glass faceplate, gloss white
• Metal mounting bracket included
• Compatible with LED and halogen lighting
• Quick installation on existing wiring, neutral not required at the switch
• Modern, elegant design suitable for residential and commercial projects

Pack contents

• 1 x touch switch - two-way, 1 button (ref. T01S)
• 1 x glass faceplate - 1 button, white, gloss (ref. A-C1-11B)

Installation & compatibility

• Compatible with round or square back boxes ≥ 40 mm
• Horizontal or vertical mounting
• For use on a standard electrical installation
• Neutral wire not required at the switch (only at the light fitting)
• Compatible light sources: LED and halogen

What's in the box

• 1 two-way 1-button touch switch mechanism
• 1 glass faceplate - 1 button, white, gloss
• 1 metal mounting bracket
• 1 installation guide

Caractéristiques / spécifications techniques

• Manufacturer: Livolo
• Reference: PP-T01S-A13B
• Type: Touch faceplate
• Number of circuits: 1 lighting circuit
• Minimum load: 5 W
• Certification: CE & RoHS
• Maximum power: 2000 W
• Material: Tempered glass
• Categories: Ready-to-fit products Switch
• Function: Ready-to-fit two-way switch (Two-way)
• Number of buttons: 1
